250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator
250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator
250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator
250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator
250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator
250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator
250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator
250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator
Specifications
Brand Name :
Global Power
Model Number :
GP K250
Certification :
OEM / ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1 Set
Price :
Negotiable
Supply Ability :
2000 Sets per Year
Delivery Time :
30 working days after received down-payment
Packaging Details :
Plastic foam or plywood case packing
Product Name :
Open Diesel Generator Set
Prime Power :
250KW / 300KVA
Standby Power :
275KW / 344 KVA
Engine Brand :
KOFO
Engine Model :
WT 12D-308E
Alternator Brand :
WATTEK
Alternator Model :
WHI4DC
Dimension(L*W*H) :
3000*1150*1800 MM
Weight :
2550KG
Description

Global Power Brushless AC Generator Set: KOFO Series GPK 250 Diesel Genset 1500 RMP Price

Global Power diesel-powered generator is a favorite in the industry. It is highly reliable in providing emergency power in the event of an outage. This generator set is the epitome of dependability with its reliable mechanical and electrical performance. It uses the mature technology perfected by KOFO to provide clean and modern diesel-powered generators.

250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator

Genset Model GPK250
Prime Output (KW / KVA) 250 KW / 313 KVA
Standby Output (KW / KVA) 275 KW / 344 KVA
Voltage, Phase and Wire 400 V / 3 Phase / 4 Wires
Maximum Output Current 451 AMP
Engine Brand and Model KOFO WT 12D-308E
Alternator Brand and Model WATTEK WHI4DC
Engine Speed RPM 1500
Frequency 50 HZ

Prime Power

These ratings are applicable for supplying continuous electrical power (at variable load) in lieu of commercial purchased power. There is no limitation to the annual hours of operation and this model can supply 10% overload power for 1 hr in 12hs

Standby Power

These ratings are applicable for supplying continuous electrical power (at variable load) in the event of a utility power failure. No overload permitted on these ratings. The alternator on this model is peaking continuous rated (as defined in ISO 8528-3)

ENGINE SPECIFICATION

Engine Model KOFO WT 12D-308E
Engine Type Water-cooled, 6 cylinders in line, direct injection
Maximum Output 288 KW
Aspiration Turbocharged
Bore x Stroke 125*147 mm
Displacement 14 L
Compression Ration 16:1
Fuel Consumption 188 g/kw.h
Lube-oil Pan Capacity 16.4 L
Cooling Water Capacity 24 L
Voltage for Start 24 V
Instrument for Adjusting Speed Electronic
Noise Level (A) 7 m ≤115 db (Open type), ≤75 db (Silent type)

ALTERNATOR SPECIFICATION

Alternator Model WATTEK WHI4DC
Excitation Brushless, self-excited
Insulation Class H
Project Class IP23
Connection Type Re-connectable
Voltage Regulation ≥95%～105%
Waveform ≤5%, sine wave
Distortion THF / TIF THF<50, TIF<2%

250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator

Exhaust System

  • Stainless steel industrial exhaust muffler for silent type.

Lube System

  • Lubricating oil filter; oil drain with valves
  • Lube oil pressure indicator

DIMENSIONS AND WEIGHT

Genset Type Length Width Height Weight
Open Type 3000mm 1150mm 1800mm 2550kg

250 KW / 313 KVA Open Diesel Generator Global Power Diesel Powered Generator
