Lovol Genset Generator Set 3 Phase 4 Wire 32KW 40KVA Water Cooled Diesel Generator
Lovol Genset Generator Set 3 Phase 4 Wire 32KW 40KVA Water Cooled Diesel Generator
Lovol Genset Generator Set 3 Phase 4 Wire 32KW 40KVA Water Cooled Diesel Generator
Lovol Genset Generator Set 3 Phase 4 Wire 32KW 40KVA Water Cooled Diesel Generator
Specifications
Product Name :
Diesel Power Generator Set
Output Type :
AC Three Phase
Rated Voltage: :
400/230V
Prime Power (kw/kva) :
32/40
Standby Power(kw/kva) :
35/44
Engine Model :
LOVOL, 1004G
Alternator Brand :
Global Power, GPI 184J
Frequency :
50Hz
Weight(kg) :
825
Dimension Size(L*W*H/mm) :
1857*706*1100
Package :
Plastic Foam or Plywood Case
Control Module Brand :
DeepSea,Comap,Smartgen
Brand Name :
Global Power
Model Number :
GPL32
Certification :
OEM/ISO9001
Place of Origin :
Jiangsu, China
MOQ :
1set
Price :
negonation
Payment Terms :
T/T or LC
Supply Ability :
2,000sets/year
Delivery Time :
25 working days after received down-payment
Packaging Details :
FOB, CRF,CIF,EXW…
Description

50Hz 3 Phase 32KW / 40KVA Open Diesel Generator ,Water-cooled With Mechanical Speed Govering Diesel Generator

Features and benefits

  1. Tightly structure, excellent design and craft
  2. Excellent cooling system, reliable performance under the harshest conditions (ambient temperature up to 40℃ and altitudes up to 1000m)
  3. Self-diagnostic capability simplifies troubleshooting
  4. LCD display shows system status and setup information
  5. Automatic voltage regulator protects your sensitive electronics from harmonic distortion and unstable power quality
  6. Soundproof type: Very quite running–75dB(A)at 23ft(7m) at normal load.
  7. Enclosed muffler for added quietness
  8. Service and maintenance accessible through easy-latch side service door

Generator data

Diesel Generator GPL32 (three phase)

Prime Power (kw/kva) 32/40
Standby Power (kw/kva) 35/44
Rated Voltage (V) 400/230
Voltage Recovery Time ≤1S
Rated Current (A) 58
Rated Frequency (Hz) 50
Frequency Recovery Time ≤5S
Wave Distortion ≤5%, sine wave
Running Noise db(A)/7m(Silent type) 75
Battery capacity (V-Ah) 12V 100Ah
Open Type-Dimension (L*W*H) (mm) 1857*706*1100
Open Type-Weight (kg) 825
Soundproof Type- Dimension (L*W*H) (mm) 2280*890*1280
Soundproof Type-Weight (kg) /
Fuel Tank Capacity(L) 170
Continuous Running Time(hr.) 8

Engine

Main features:

  1. Six-cylinder, water-cooled, in-line diesel engine
  2. Efficient fuel system for max power output and durability
  3. Large-capacity air cleaner
  4. Cost effective, fuel efficient and reliable performance
  5. Functional engine with compact structure
  6. Excellent after-sales service and sufficient spare parts supplying
  7. Easy installation and ready access for routine maintenance

Technical data

Model 1004G

Engine brand LOVOL
Output Power (kw) 40
Cylinder No. & Config. 4, in-line
Combustion System direct injection
Air Intake System Naturally aspirated
Displacement (L) 3.99
Bore X Stroke (mm) 100*127
Engine Speed (r/min) 1500
Speed Governing Mechanical
Starting System 24V DC Electric
Filter System Dry oil filter/Fuel filter/Oil filter
Cooling system Water-cooled
Fuel Consump. (g/kw·h) ≤208
Oil Consump.(g/kw.h) ≤2.5

Alternator specifications

Technical data

Model GPI 184J

Alternator brand Global Power
Rated Power (kw) 32
Excitation System Brushless, self-exciting
Voltage Regulation Mode AVR
Connection Type 3phase,4wires,”Y” connection
Pole No. 4
Rotation Speed (r/min) 1500
Temperature Rise (℃) 125
Insulation class H
Voltage Regulation (0 load) ≥95%～105%
Voltage accuracy ≤±1%
Protection Grade IP23
Telephone Influence Factor TIF＜50
Harmonic Coefficient THF＜2%

Control system

Smartgen AMF25 controller

Lovol Genset Generator Set 3 Phase 4 Wire 32KW 40KVA Water Cooled Diesel Generator

Main features:

  1. Using microprocessor as a core, graphics LCD with big screen and backlight, key touch for operation
  2. Security password-protected programming levels
  3. All parameters use digital modulation, with higher reliability and stability
  4. Built-in speed/frequency detecting units can accurately judge the states such as crank success and over speed
  5. Power supply range is wide, accommodating to different starting battery voltage environment
  6. Built-in watch dog can never be dead halt, ensuring smooth program execution
  7. Modular configuration design, inserted type connection terminals, flush type installation, compact structure, easy installation

Lovol Genset Generator Set 3 Phase 4 Wire 32KW 40KVA Water Cooled Diesel Generator
