Specifications
Brand Name :
ruiting
Model Number :
RTFQ-2500
Certification :
CE
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
30 sets per month
Delivery Time :
30 working days
Packaging Details :
wooden case
Weight :
3800KGS
Warranty :
1 Year
Computerized :
Yes
Voltage :
380V
Dimension(l*w*h) :
2400*3500*1700mm
Product name :
2500 Jumbol Kraft Paper Roll Slitting Machine with round knife
Speed :
200m/min
Precision :
±0.1mm
Max.rewind diameter :
500mm
Max unwinding diameter :
1200mm
Description

2500 Jumbol Kraft Paper Roll Slitting Machine with round knife

Product Description

This machine slitting material from jumbol wide roll to small narrow rolls. It can cut different material, like paper, film, PVC , nonwven fabric and so on material. The machine can use both round knife, razor knife.

Main features

1) Meter counting

2) One photoelectric eye for web guide

3) 8 sets rotary blade for slit paper(If you need also slit film, can add 8 sets straight knife)

4) 3 inch air shaft for both unwinding and rewinding

5) Automatic loading

6) Auto tension control

7) Max unwinding diameter 1200mm

8) Max rewinding diameter 600mm

Main Technical Specification:

Max web width 2500mm
Max rewinding diameter 500mm
Max. unwinding diameter 1200mm
Min width 25mm
Power Supplier AC380V, 3 phase
Cutting precision 0.2mm
Cutting speed 10-200m/min
Overall dimensions(L*W*H) 2.4*3.5*1.7m
Machine weight 3800kg
