10G LC to LC Fiber Optic Pigtails / OM3 Mm Fiber Patch Cords 2.0mm OD
10G LC to LC Fiber Optic Pigtails / OM3 Mm Fiber Patch Cords 2.0mm OD
10G LC to LC Fiber Optic Pigtails / OM3 Mm Fiber Patch Cords 2.0mm OD
10G LC to LC Fiber Optic Pigtails / OM3 Mm Fiber Patch Cords 2.0mm OD
Specifications
Brand Name :
Hangalaxy
Model Number :
HGYN-0160
Certification :
CE, SGS, UL, ROHS
Place of Origin :
China
MOQ :
MOQ Saying is 10pcs
Price :
Negotiation By email or Phone Call
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25000PCS Monthly
Delivery Time :
7-10 Business Days
Packaging Details :
1PCS Each Individual Quality PE Bag
Connector 1 :
LC
Connector 2 :
LC
Polish Type :
UPC
Cable OD :
2.0mm
Cable Color :
Aqua
Cable Jacket :
LSZH
Fiber Mode :
Multimode
Wavelength :
850nm
Description

2.0mm 10G LC to LC Fiber Multimode OM3 Optic Pigtails Simplex Patch Cable

Features

(1) Standard length of three meters. Custom lengths available upon request;
(2) All connectors have precision pre-radiused zirconia ferrules;
(3) Corning glass fiber or equivalent;
(4) Other connectors available upon request (MU, FC, MT-RJ);
(5) 0.9 mm tight buffered OFNR cable (white) in 62.5/125 μm, 50/125 μm, 50/125.

Applications

1. Active device termination;
2. CATV system;
3. Active device terminations;
4. LAN / WAN;
5. FTTx (including FTTB, FTTC, FTTD, FTTH).

Technical Parameter

Fiber Type SM MM

Connector Tytpe

 MTRJ

D4, FC, SC, ST, LC,

E-2000, MU

D4, FC, SC, ST, LC,

E-2000, MU

 MTRJ
Insertion Loss (Typical) ≤0.4dB ≤0.2dB ≤0.4dB ≤0.2dB
Insertion Loss (Max) ≤0.5dB ≤0. 3dB ≤0.3dB ≤0.5dB

Return Loss (Typical)

 PC ≥50dB
APC ≥65dB
UPC ≥55dB ≥55dB
Mating Durability ≤0.2dB
Durability ≥1000 times
Storage Temperature - 40℃～+ 85

Cable Diameter 0.9mm
Jacket Color Yellow or Customized
Connector LC
Polishing Type APC
Fiber Type G657A1, SM, Single-mode
Cable Length 1m / 10ft; or customized

Environmental Space Plenum
Operating Temperature -10 °C to +60 °C (+14 °F to +140 °F)

PLC Spliters Workshop

10G LC to LC Fiber Optic Pigtails / OM3 Mm Fiber Patch Cords 2.0mm OD

Quality Guarantee

Hangalaxy has those fiber optical patch cables in stock and ready to ship. This cable is tested for 100% functionality and guaranteed compatible for outstanding network performance. Now you have a reliable, compatible and affordable means to expand your network while maintaining its integrity. We can provide this cable in any lengths. If the length you need is not listed on our website, please feel free to contact us.
