3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2
3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2
3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2
3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2
3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2
3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2
3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2
3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2
Specifications
Brand Name :
Hangalaxy
Model Number :
HGYN-014
Certification :
CE, SGS, UL, ROHS
Place of Origin :
China
MOQ :
MOQ Saying is 10pcs
Price :
Negotiation By email or Phone Call
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25000PCS Monthly
Delivery Time :
7-10 Business Days
Packaging Details :
1PCS Each Individual Quality PE Bag
Connector 1 :
FDDI
Connector 2 :
ST
Polish Type :
UPC
Cable OD :
3.0mm
Cable Color :
Yellow
Cable Jacket :
LSZH
Description

3.0mm FDDI to ST Fiber Singlemode OS2 Optic Pigtails Duplex Patch Cable

Description

Hangalaxy manufactures fiber patch cords using the highest quality cable and connectors. All assemblies are tested to ensure low db loss. We stock an extensive range of standard length cables for your convenience. Same day shipment is available for many patch cables! Save time and money by purchasing multi-fiber assembled cables in custom lengths and eliminate the need for field assembly. Hangalaxy manufactures cables using any combination of connectors and cable types. The choice is yours, call with your specific requirements.

Features

● Available in custom lengths and arrangements.

● Single-Mode or Multi-Mode fiber.

● Simplex, Duplex, Ruggedized or Multi-Fiber cable.

● ST, SC, FDDI, FC, BICONIC, ESCON, SMA905, SMA906, MINI BNC, MTRJ, D4, LC, or as per customer special requirements.

Applications

1. Provides point to point connection for fiber optic equipment;

2. CATV & CCTV;

3. Fiber Optic Telecommunications;

4. LAN (Local Area Network);

5. FTTH (Fiber To the Home);

6. High speed transmission Systems.

Technical Parameter

Fiber Type SM MM

Connector Tytpe

 MTRJ

D4, FC, SC, ST, LC,

E-2000, MU

D4, FC, SC, ST, LC,

E-2000, MU

 MTRJ
Insertion Loss (Typical) ≤0.4dB ≤0.2dB ≤0.4dB ≤0.2dB
Insertion Loss (Max) ≤0.5dB ≤0. 3dB ≤0.3dB ≤0.5dB

Return Loss (Typical)

 PC ≥50dB
APC ≥65dB
UPC ≥55dB ≥55dB
Mating Durability ≤0.2dB
Durability ≥1000 times
Storage Temperature - 40℃～+ 85

Cable Diameter 0.9mm
Jacket Color Yellow or Customized
Connector LC
Polishing Type APC
Fiber Type G657A1, SM, Single-mode
Cable Length 1m / 10ft; or customized

Environmental Space Plenum
Operating Temperature -10 °C to +60 °C (+14 °F to +140 °F)

3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2

PLC Spliters Workshop

3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2

Hangalaxy Exhibition Activities

3.0mm FDDI to ST Fiber Optic Pigtails / Single Mode Fiber Pigtails OS2

Packing Information

1PCS Each Individual Quality PE Bag.

If you feel any more request about the fiber optic connectivity, please give us a email and a call for asking and we will try our best service for you.
