2.0mm 10G LC to LC Fiber Multimode OM3 Optic Pigtails Simplex Patch Cable

Description

The single-mode and multimode fiber optic pigtails shall be available in 3-meter lengths, made of OFNR fiber optic cable, and be compliant with TIA-568-C.3. Single-mode pigtails shall come in ST, SC, and LC connector styles, and offer UPC and APC polish types. Insertion loss shall average .3dB, but not exceed .5dB at 1310 nm and 1550nm per mated pair. Multimode pigtails shall come in ST, SC, and LC connector styles, and offer 50 μm (10G, 300 m) lazer optimized, and 62.5 μm core styles. Insertion loss shall average .3dB, but not exceed 0.5dB at 1300 nm per mated pair. Hangalaxy’s single-mode, standard multimode, and laser optimized multimode fiber optic pigtails are designed to support mechanical and fusion splicing for fiber cabling systems.

Features

(1) Standard length of three meters. Custom lengths available upon request;
(2) All connectors have precision pre-radiused zirconia ferrules;
(3) Corning glass fiber or equivalent;
(4) Other connectors available upon request (MU, FC, MT-RJ);
(5) 0.9 mm tight buffered OFNR cable (white) in 62.5/125 μm, 50/125 μm, 50/125.

Applications

1. Active device termination;
2. CATV system;
3. Active device terminations;
4. LAN / WAN;
5. FTTx (including FTTB, FTTC, FTTD, FTTH).

Technical Parameter

PLC Spliters Workshop

Quality Guarantee

Hangalaxy has those fiber optical patch cables in stock and ready to ship. This cable is tested for 100% functionality and guaranteed compatible for outstanding network performance. Now you have a reliable, compatible and affordable means to expand your network while maintaining its integrity. We can provide this cable in any lengths. If the length you need is not listed on our website, please feel free to contact us.
