PV7-2X/20-25RA01KA0-10 PV7-1X/06-10RA01MA0-10 PV7-2X/20-25RA01MA0-05 PV7 series German imported Rexroth vane pump
PV7-2X/20-25RA01KA0-10 PV7-1X/06-10RA01MA0-10 PV7-2X/20-25RA01MA0-05 PV7 series German imported Rexroth vane pump
PV7-2X/20-25RA01KA0-10 PV7-1X/06-10RA01MA0-10 PV7-2X/20-25RA01MA0-05 PV7 series German imported Rexroth vane pump
PV7-2X/20-25RA01KA0-10 PV7-1X/06-10RA01MA0-10 PV7-2X/20-25RA01MA0-05 PV7 series German imported Rexroth vane pump
Specifications
Brand Name :
Rexroth
Model Number :
PV7-2X/20-25RA01KA0-10 PV7-1X/06-10RA01MA0-10 PV7-2X/20-25RA01MA0-05
Certification :
ISO
Place of Origin :
German
MOQ :
1
Payment Terms :
MoneyGram,Western Union,T/T,D/P,D/A,L/C
Supply Ability :
100
Delivery Time :
2 weeks
Packaging Details :
wooden box
Case Drain Flow (at Rated Pressure) :
1.5–2.5
Question :
Answer
What is the model range of the direct-acting PV7 series? :
PV7-1X/06-10RA01MA0-10, PV7-2X/20-25RA01MA0-10
What does "1X/2X" represent in the PV7 model code? :
It indicates the component series of the pump
What is the displacement per revolution range of the direct-acting PV7 series? :
10–25 cm³/rev
What is the displacement per revolution range of the pilot-operated PV7 series? :
14–150 cm³/rev
Description

PV7-2X/20-25RA01KA0-10
PV7-1X/06-10RA01MA0-10
PV7-2X/20-25RA01MA0-05 PV7 series German imported Rexroth vane pump

Index Data Range
Volumetric Efficiency ≥90% (at rated pressure and speed)
Total Efficiency ≥80% (at rated working condition)
Noise Level ≤65 dB(A) (at 1 m distance under rated operation)
Suction Pressure -0.8 bar to +1 bar (absolute pressure: 0.2–1.1 bar)

PV7-2X/20-25RA01KA0-10 PV7-1X/06-10RA01MA0-10 PV7-2X/20-25RA01MA0-05 PV7 series German imported Rexroth vane pump

PV7-2X/20-25RA01MA3-05
PV7-1X/06-10RE01MA0-05
PV7-2X/20-25RA01MA3-10
PV7-1X/06-10RE01MA0-10
PV7-2X/20-25RE01MA0-05
PV7-1X/06-10RE01MA3-10
PV7-2X/20-25RE01MA0-10
PV7-1X/06-10RG01MA0-05
PV7-2X/20-25RE01MA3-05
PV7-1X/06-10RG01MA0-10
PV7-2X/20-25RE01MA3-10
PV7-1X/06-10RG01MA3-10
PV7-1X/06-14RE01MA3-07
PV7-1X/06-14RA01MA0-04
PV7-1X/06-14RG01MA0-07
PV7-1X/06-14RA01MA0-07
PV7-2X/20-20RA01MA0-05
PV7-1X/06-14RA01MA3-04
PV7-2X/20-20RA01MA0-10
PV7-1X/06-14RA01MA3-07
PV7-2X/20-20RA01MA3-05
PV7-1X/06-14RE01MA0-04
PV7-2X/20-20RA01MA3-10
PV7-1X/06-14RE01MA0-07
PV7-2X/20-20RE01KA0-10
PV7-1X/06-14RE01MA3-04
PV7-1X/06-10RA01MA0-05-P50
PV7-2X/20-20RA01MA0-10-P85
PV7-1X/06-10RA01MA0-10-P50
PV7-2X/20-25RA01MA0-05-P32
PV7-1X/06-14RA01MA0-07-P50
PV7-2X/20-25RA01MA0-05-P50
PV7-1X/06-14RA01MA0-07-P65
PV7-1X/06-14RA01MA0-07-P70
PV7-2X/20-20RA01MA0-10-P65
PV7-2X/20-20RA01MA0-05-P25
PV7-2X/20-20RA01MA0-05-P50
PV7-1X/06-14RA01MA0-10-A473
PV7-1X/06-10RA01MA0-10-P100
PV7-1X/06-14RA01MA0-10-A492
PV7-2X/20-20RA01MA0-10-C3.1
PV7-2X/20-20RA01MA0-05-A480
PV7-2X/20-20RA01MA0-10-A480
PV7-1X/06-10RA01MA0-10-C3.1
PV7-2X/20-20RA01MA0-10-P100
PV7-2X/20-25RA01MA0-05-P24Q30

FAQ:

1. What is the required flatness of the PV7 pump mounting surface?
The flatness should be ≤0.1mm/m; use a straightedge and feeler gauge for inspection.

2. Can the PV7 pump be installed vertically (inverted)?
No, horizontal mounting is recommended (shaft extension horizontal or upward) to avoid poor internal lubrication and bearing overheating.

3. What is the maximum allowable suction height for the PV7 pump?
≤0.5m (distance from tank liquid level to pump suction port); increase pipe diameter or add an auxiliary suction pump if exceeded.

4. What type of coupling should be used for PV7 pump installation?
Flexible couplings (e.g., plum-blossom or jaw-type) are mandatory; rigid couplings are prohibited.

5. What is the required coaxiality between the PV7 pump and motor?
Coaxiality ≤0.05mm; check with a dial indicator to prevent shaft bending and bearing damage.
