Single-group Conversion Type General-purpose Small Relay D15.6XL19.2MM PCB Installation SRD-12VD-SL-C

Contact form

Contact resistance

Contact material

Contact load

Maximum switching voltage

Maximum switching current

Maximum switching power

Electrical life (frequency: 1800 per hour

18000

"Second

Mechanical life (frequency: times per hour)

A/B/C

100mΩ(1A 6VDC)

Silver alloys :AgCdO, AgSnO2, AgNi

7A/250VAC 10A/250VAC 15A/250VAC

250VAC

15A

3750VA

1x10 times / 1x10 times

1x10 times

Insulation class

Insulation resistance

Medium pressure resistance

(Leakage current 1mA

Between the coil and the contact

Disconnect between the contacts

Engagement time (at rated voltage)

Release time (at rated voltage)

Humidity

Ambient temperature

Impact-resistant

Stability

"Strength"

Anti-vibration (dual amplitude

Weight

Encapsulation form

100MQ(500VDC)

1500VAC for 1 minute

1000VAC for 1 minute

<10ms

<10ms

85% RH(20'C)

40'C-+85'C/-40C-+105'0

98m/s2

980m's?

10 hz ~ 55 hz1. 5 mm

About 9g

Sealed type

Packaging and transportation instructions

- According to the standard export packaging.

Customers can choose from cartons, wooden cases and wooden pallets according to their own requirements.
