Indoor AIS Base Station All In One Solution For Maritime Control Rooms
Indoor AIS Base Station All In One Solution For Maritime Control Rooms
Indoor AIS Base Station All In One Solution For Maritime Control Rooms
Indoor AIS Base Station All In One Solution For Maritime Control Rooms
Indoor AIS Base Station All In One Solution For Maritime Control Rooms
Indoor AIS Base Station All In One Solution For Maritime Control Rooms
Indoor AIS Base Station All In One Solution For Maritime Control Rooms
Indoor AIS Base Station All In One Solution For Maritime Control Rooms
Specifications
Brand Name :
Dexonmarine
Model Number :
DX083IA
Certification :
ISO9001,IEC, IALA
Place of Origin :
Chengdu
MOQ :
1
Price :
usd$2000-3000
Payment Terms :
L/C,T/T,Western Union,MoneyGram
Supply Ability :
10000pcs/month
Delivery Time :
3-10days
Packaging Details :
cartons/pallets
Waterproof :
IP68
Local Storage :
Expandable, supports up to 64GB
AIS Transmission distance :
20-25nm
Message :
Message 21, 6, 8, 14; supports multiple formats
Materia :
FRP (Fiberglass Reinforced Plastic)
Power Supply Range :
AC 220V or DC 8~32V
Lifespan :
15 years
Average Power Consumption :
Approx. 1W in continuous operation
Certifications :
CE, RoHS, ISO,IEC, IALA
Interface Types :
RS232, RS485, RJ45
Applications :
ideal for manufacturers, engineering teams, and maintenance crews operating in coastal areas, offshore channels, and remote waterways, providing efficient, real-time monitoring and targeted maintenance without the need for traditional large-scale AIS base
Service :
Logo OEM , customized detailed requiements
Description

DX083IA Iutdoor AIS Base Station –Designed for Control Rooms, Port Offices, and Shore-Based Monitoring

The DX083IA Indoor AIS Base Station is a compact, all-in-one solution designed for maritime control rooms, port management offices, and shore-based monitoring stations. It is an ideal solution for indoor environments where space is limited and protection from outdoor conditions is essential. This device integrates AIS signal reception, data output (RS232/Ethernet), and optional 4G/5G communication in one unit. The DX083IA boasts a modular architecture, built-in diagnostics, and stable 24/7 operation, making it a reliable and low-maintenance platform for managing AIS data from ships and navigation aids within the coverage area.

Indoor AIS Base Station All In One Solution For Maritime Control Rooms

KEY ADVANTAGES

  • All-in-One Integrated Design
    Combines receiver board, power unit, GPS/VHF antennas, and network interface in a single compact enclosure.

  • Optimized for Indoor Use
    Ideal for deployment in control rooms, port offices, and technical cabinets—no exposure to harsh outdoor conditions.

  • Stable and Continuous AIS Reception
    Receives AIS signals from vessels, AtoNs, and base stations within range for reliable real-time monitoring.

  • Flexible Data Interfaces
    Supports RS232 and Ethernet outputs; optional 4G/5G wireless communication for extended network access.

  • Modular, Open Architecture
    Allows for easy integration with existing maritime systems and supports future software expansion.

  • Low Maintenance Operation
    Features built-in diagnostic tools and self-healing software functions, minimizing system downtime.

  • Standards-Compliant
    Conforms to IEC 62287-1, IEC 61108-1, IEC 60945, IEC 61162-1, ITU-R M.825-3, and other international standards.

TECHNICAL DATA

Parameter

Specification

Power Supply Range

AC220V / DC12V ( adjustable)

Operating Frequency Range

156.025–162.025 MHz

Frequency Error

±0.3 kHz

Receiving Sensitivity

≤ -107 dBm

Average Power Consumption

Approx. 1W in continuous operation mode

Transmission Power

12.5W or 6W (default: 6W)

Interface Types

RS232, RJ45 Ethernet port

Data Format

NMEA 0183

Transmission Rate

115200 bps

Message Format

VDM

Virtual Beacon Functionality

Expandable, supports up to 8 virtual beacons

Operating Temperature

-30°C to +65°C

4G/5G Wireless Communication

Expandable

Dimensions

483mm × 409mm × 135.5mm

Weight

≤ 5kg

HOW TO CONNECT

Indoor AIS Base Station All In One Solution For Maritime Control Rooms

AIS Base Station Model Comparison

Feature DX081PB (Portable AIS Base Station) DX082FA (Outdoor AIS Base Station) DX083IA (Indoor AIS Base Station)
Installation Location On-site / Temporary setup Coastal / Tower / Platform Indoor control rooms / technical cabinets
Use Scenario Field testing, buoy inspection, mobile use Fixed installation for long-term AIS monitoring Port offices, inland monitoring centers
Power Supply Rechargeable battery (200h use) Mains-powered or solar + battery backup Mains-powered
Waterproof Level Basic weather resistance (splash-proof or IP68) IP68 waterproof, anti-corrosion IP65 waterproof
Portability High – handheld or carried Low – permanently mounted Low – fixed indoor use
Typical Deployment Navigation aid testing teams, inspection vessels Ports, offshore platforms, coastal monitoring Port command centers, traffic control rooms
