PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
Specifications
MOQ :
1
driven type :
Electric
key selling points :
Long Service Life
After-sales Service Provided :
Video Technical Support, Field installation, commissioning and training, Online support, Free Spare Parts
Filling range :
6-60ml, 10-150ml, 25-250ml customized
dimension(l*w*h) :
L1630mm*W1380mm*H1600mm
machinery test report :
Provided
filling nozzle :
1
Place of Origin :
Guangdong, China
core components :
PLC, Engine, Motor
Dimensions (L*W*H) :
L1630mm*W1380mm*H1600mm
packaging type :
Cartons
Weight (KG) :
180
Power supply :
1P/220V/50Hz, 2.6KW
Price :
$5,000-6,000
Voltage :
110 V, 220 V, 380 V
video outgoing-inspection :
Provided
packaging material :
Wood, Other
Weight :
450kg
Capacity :
22-28 PCS/Min
Payment Terms :
TT
Air Pressure :
0.4-0.6MPa
Filling accuracy :
±1%
automatic grade :
Automatic
Model :
CM-AFS-03
Delivery Time :
7 work days
warranty :
1 Year
filling accuracy :
±0.1%
Brand Name :
COSMATI
application :
Chemical, Cosmetic, Other
Filling Volume :
10-250ml (can be customized)
filling material :
Cream, Water, Oil, Other
Product name :
Semi Automatic soft tube filling and sealing machine
Packaging Details :
wooden cases
Supply Ability :
10000 set
Description
Automatic Rotary Hand Cream Gel Sample Toothpaste Filler Making Machine Ultrasonic PET Tube Filling and Sealing Machine

Introduction
The soft tube filling and sealing machine is suitable for all kinds of plastic tubes, aluminum-plastic composite tubes, automatic filling and sealing, color coding, date printing, trimming and tube outlet, suitable for ointment, toothpaste, facial cleanser, conditioner, shampoo, hand cream, eye cream, hair color cream, shoe polish and other products.

Features

  1. This machine manually completes a series of actions such as dropping the tube,automatic labeling, filling, sealing and printing, cutting the tail, and outputting the finished product;
  2. This machine is equipped with safety device, no tube no filling, no tube no tail sealing, tail cutting, overload protection;
  3. Suitable for filling sealing soft tubes, such as toothpaste, hand cream, eye cream, face cleanser, shampoo, hair dye, etc. It is an ideal equipment for cosmetic tube.
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
Detail
Capacity
Dimension(mm)
Power supply
Sealing diameter
Filling accuracy
20-25 tubes/min.
L900*W1100*H1600mm
220v/380v, 2.6KW
16-50mm
±1%
Filling range
Weight
Hopper volume
Sealing height
Body material
6-60ml/10-120ml/
25-250ml(Optional)
420KG
40L
50-250mm
SUS304

Factory profile
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel

Engineer case
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel

Trade show participation
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
Packaging & shipping specifications
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel
Application
PET Rotary Ultrasonic Tube Filling Sealing Machine for Hand Cream Toothpaste Gel

FAQ

Q1: What products can this rotary tube filling and sealing machine fill?
A: It is suitable for hand cream, toothpaste, gel, facial cleanser, lotion, cosmetic cream and other liquid or semi-viscous products.

Q2: What type of tubes can the machine process?
A: It is mainly suitable for PET and compatible plastic soft tubes. Tube material, diameter, length and sealing area should be confirmed before ordering.

Q3: What sealing method does the machine use?
A: The machine uses ultrasonic sealing technology to provide a clean and stable tube seal.

Q4: Is this machine fully automatic?
A: Yes. It is an automatic rotary model designed to complete tube positioning, filling and sealing through a continuous rotary working process.

Q5: How many filling nozzles does the machine have?
A: The standard configuration shown uses one filling nozzle.
