AC 220V 0.003Mm Accuracy 5 Axis CNC Machine With 20 Tool Magazine Capacity
AC 220V 0.003Mm Accuracy 5 Axis CNC Machine With 20 Tool Magazine Capacity
AC 220V 0.003Mm Accuracy 5 Axis CNC Machine With 20 Tool Magazine Capacity
AC 220V 0.003Mm Accuracy 5 Axis CNC Machine With 20 Tool Magazine Capacity
AC 220V 0.003Mm Accuracy 5 Axis CNC Machine With 20 Tool Magazine Capacity
AC 220V 0.003Mm Accuracy 5 Axis CNC Machine With 20 Tool Magazine Capacity
Specifications
Brand Name :
LiSN
Model Number :
LiSN-WZ500
Place of Origin :
China
Certification :
CE
MOQ :
1
Payment Terms :
T/T, L/C
Supply Ability :
10000 per year
Delivery Time :
60-70work days
Packaging Details :
wooden box
Tool Magazine Capacity :
20
Spindle Speed :
15000 Rpm
Power Supply :
AC 220V
Maximum Tool Diameter :
300 Mm
Accuracy :
0.003 Mm
Maximum Workpiece Diameter :
1000 Mm
Spindle Power :
10 KW
Description

High Precision 5 Axis Linkage with 20 Tool Magazine Capacity

Product Description:

5 Axis Linkage - Precision CNC Machine Tools

The 5 Axis Linkage is a state-of-the-art CNC machine designed for precision machining. With advanced technology and high efficiency, this machine is perfect for a wide range of industries and applications.

Product Overview

The 5 Axis Linkage is a versatile CNC machine that offers exceptional performance and precision. It is equipped with 5 axes, allowing for complex and precise machining operations. This machine is ideal for manufacturing components, parts, and products with high accuracy and quality.

Key Features

The 5 Axis Linkage can accommodate tools with a maximum diameter of 100 mm, making it suitable for a variety of machining operations.

With a maximum workpiece diameter of 1000 mm, this machine can handle larger workpieces with ease, providing enhanced flexibility and versatility.

The 5 Axis Linkage offers a high level of repeatability, ensuring consistent and accurate results with every machining operation.

The machine is equipped with an advanced oil mist coolant system, which provides efficient cooling and lubrication during the machining process, resulting in better surface finish and longer tool life.

Technical Parameters:

Item Specifications Unit Parameters of LISN-WZ500
Work Table Work Table Size mm 500
A-Axis Swing Angle ° ±120
C-Axis Swing Angle ° 360
A-Axis Swing Speed rpm 30
C-Axis Swing Speed rpm 50
Max.Load of Work Table kg 200
Work Range X-Axis Travel Range mm 600
Y-Axis Travel Range mm 700
Z-Axis Travel Range mm 450
Distance between Spindle Nose to Work Table mm 120-570
Spindle Spindle Speed Range r/min 15000
Spindle Motor Kw 11
Feedrate X/Y/Z Axis Rapid Feed Speed m/min 24/24/24
X/Y/Z Axis Feed Speed m/min 10
ATC Tool Capacity - 20
Position Accuracy X/Y/Z Axis Position Accuracy mm 0.005
A-Axis s ±40
C-Axis s ±25
Re-position Accuracy X/Y/Z Axis Re-position Accuracy mm 0.003
A-Axis s ±4
C-Axis s ±4
Total Electrical Capacity KVA 35
Machine Dimenssion Size mm 2500×2900×3000

Product details:

AC 220V 0.003Mm Accuracy 5 Axis CNC Machine With 20 Tool Magazine Capacity
AC 220V 0.003Mm Accuracy 5 Axis CNC Machine With 20 Tool Magazine Capacity

FAQ:

1. Is it all right to make customer's own brand name?

A: yes. we are available with OEM

2. Are you a manufactuer or trading company?

A:We are the manufacturer

3. Can you do the design for us?

A: yes. if you want a different control system design or higher column , we are available.

4 . What is your terms of delivery?

A: FOB shenzhen.

5. What's your payment term?

A: T/T OR L/C at sight.
