AESSEAL LSEAL Cartridge Mechanical Seals for Flowserve Process Pumps
AESSEAL LSEAL Cartridge Mechanical Seals for Flowserve Process Pumps
AESSEAL LSEAL Cartridge Mechanical Seals for Flowserve Process Pumps
AESSEAL LSEAL Cartridge Mechanical Seals for Flowserve Process Pumps
AESSEAL LSEAL Cartridge Mechanical Seals for Flowserve Process Pumps
AESSEAL LSEAL Cartridge Mechanical Seals for Flowserve Process Pumps
AESSEAL LSEAL Cartridge Mechanical Seals for Flowserve Process Pumps
AESSEAL LSEAL Cartridge Mechanical Seals for Flowserve Process Pumps
AESSEAL LSEAL Cartridge Mechanical Seals for Flowserve Process Pumps
AESSEAL LSEAL Cartridge Mechanical Seals for Flowserve Process Pumps
Specifications
Brand Name :
BESTSEAL
Stationary Face :
TC / Ceramic / SiC
Clamp Ring :
316L Stainless Steel
Place of Origin :
CHINA
Sleeve O Ring :
FKM / EPR / FFKM / TFE/P
Spacer Ring :
316L Stainless Steel
Packaging Details :
Carton
Model Number :
LSEAL
Rotary Bellows Face - SAC :
316 SS - AM350 - C42 - Carbon / TC / SiC
Setting Clip Screws :
Stainless Steel
Setting Clips :
Zinc Alloy / Metal
Rotary Bellows Face - SHS :
316 SS - Alloy 276 - 316 SS - Carbon / TC / SiC
Stationary Sealing Ring :
FKM / EPR / FFKM / TFE/P / Graphite
Gasket :
AF1 / GFT
Rotary Bellows Face - HHH :
Alloy 276 - Alloy 276 - Alloy 276 - Carbon / TC / SiC
Drive Screws :
Stainless Steel
Anti-tamper Screws :
Stainless Steel
MOQ :
1pc
Supply Ability :
1000000/Month
Delivery Time :
15 working days
Sleeve :
316L Stainless Steel
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
Rotary Drive Screws :
Stainless Steel
Gland :
316 Stainless Steel
Certification :
ISO9001
Rotary Face Sealing Ring :
FKM / EPR / FFKM / TFE/P / Graphite
Description

AESSEAL LSEAL Double Seal Cartridge Mechanical Seals for Flowserve Non-metallic Process Pumps

Cartridge Mechanical Seals

Double Seals

LSEAL

L-Series Seal

The LSEAL™ is designed to suit the Flowserve Polychem 'L' Series, Group I and Group II non-metallic process pumps. This unique cartridge design simplifies installation and impeller adjustment.

Features

  • Pre-set and factory assembled
  • Available in a wide range of face and elastomer combinations
  • Patented design
  • Genuine one-piece cartridge design for reliable installation

Performance Capabilities

Temperature -20℃ to 200℃, dependent on the elastomer
Pressure Up to 2.5MPA
Speed Up to 15 m/s
End play/axial float allowance ±0.1mm
Brand BESTSEAL
Face Carbon, SiC, TC
Seat Ceramic, SiC, TC
Elastomer NBR, EPDM, FKM etc.
Spring SS304, SS316
Metal parts SS304, SS316
Packing Individual packing ,1 pc in 1 small box is available as well
