Specifications
Delivery Time :
15 working days
Rotary Drive Screws :
Stainless Steel
Setting Clips :
Zinc Alloy / Metal
Model Number :
CURC - CRCO - CURE
Rotary Bellows Face - SHS :
316 SS - Alloy 276 - 316 SS - Carbon / TC / SiC
Stationary Face :
TC / Ceramic / SiC
MOQ :
1pc
Packaging Details :
Carton
Sleeve :
316L Stainless Steel
Drive Screws :
Stainless Steel
Sleeve O Ring :
FKM / EPR / FFKM / TFE/P
Supply Ability :
1000000/Month
Gland :
316 Stainless Steel
Setting Clip Screws :
Stainless Steel
Clamp Ring :
316L Stainless Steel
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
Spacer Ring :
316L Stainless Steel
Rotary Bellows Face - SAC :
316 SS - AM350 - C42 - Carbon / TC / SiC
Stationary Sealing Ring :
FKM / EPR / FFKM / TFE/P / Graphite
Certification :
ISO9001
Rotary Face Sealing Ring :
FKM / EPR / FFKM / TFE/P / Graphite
Place of Origin :
CHINA
Anti-tamper Screws :
Stainless Steel
Gasket :
AF1 / GFT
Brand Name :
BESTSEAL
Rotary Bellows Face - HHH :
Alloy 276 - Alloy 276 - Alloy 276 - Carbon / TC / SiC
Description

AESSEAL CURC CRCO CURE Single Cartridge Mechanical Seals for ANSI Pumps

Cartridge Mechanical Seals

Single Seals

CURC - CRCO - CURE

Single Mechanical Seal

The AESSEAL® CURC™, CRCO™ and CURE™ mechanical seals are part of a range of seals specifically designed to optimize the use of Silicon Carbide.

All these seals incorporate improved third generation self aligning technology. The design objective was to minimize metal to Silicon Carbide impact, particularly on start–up.

In some seal designs, impact between metal anti–rotation pins and Silicon Carbide can be sufficiently severe to induce stress cracking in the Silicon Carbide. Silicon Carbide has many advantages when used in mechanical seals. The material has superior chemical resistance, hardness and heat dissipation properties compared to practically any other material used as a mechanical seal face. Silicon Carbide is, however, brittle by nature, so the design of the self–aligning stationary in the CURC™ range of mechanical seals seeks to minimize this metal to Silicon impact on start–up.

ATEX Range Certifications

CURC

Category 2 (Zone 1/21) & Category 3 (Zone 2/22)

Features

  • Hard-plated and replaceable cartridge sleeve extends lip seal life and eliminates shaft wear
  • Self Aligning stationary face, maximizing seal life
  • Stationary face with radial locating pins minimizes damage in stop / start applications with viscous fluids
  • Hydraulically balanced seal face technology for reduced power consumption
  • Non-clogging rotaries and non shaft fretting elastomers
  • Quench flush and drain ports for cooling or heating options to maximize seal life
  • CRCO™ lip seal option
  • CURE™ secondary seal option
  • ANSI+ gland options
  • Bi-Metal option with exotic alloy wetted components for maximum versatility at minimum price premium
  • Multiple spring and positive set screw shaft drive

Single Seals with Environmental Control Options

General service applications are efficiently sealed with an ‘O’ ring mounted, balanced, self–aligning seal. The SAI™, CS™, USI™ and NSI™ component seals and the SCUSI™ and Convertor II™ cartridge seals effectively seal all general service applications.

At the other end of the application spectrum, hazardous and dangerous products demand an engineered sealing approach. Double seals with closed–loop convection tank systems provide the necessary back–up protection.

Between these application extremes lie non–lubricating and/or non–hazardous fluids that alter their state with environmental changes. A single seal, with an API type gland, provides temperature control and protection from atmospheric contact for these applications.

Secondary fluids introduced through the Quench and Drain ports to the atmospheric side of the seal faces, control the environment without dilution of the process fluid. Water, steam, grease, oil and other suitable barrier fluids can be used.

BESTSEAL — Your Reliable Partner for Mechanical Seals

BESTSEAL Advantage:
15 years Focused in mechanical seal manufacturing
3 hours Quotation response only takes 3 hours
1 day Provide production assembly drawings
1 piece MOQ, One piece can also be produced
15-20 working days The production cycle only takes 15-20 working days
real-time Real time synchronization of production progress
BESTSEAL Cartridge Mechanical Seal
Your Fast-Track Alternative to AESSEAL CURC - CRCO - CURE
Custom Cartridge Mechanical Seals — From Drawing to Delivery in 15–20 Working Days
