Specifications
Rotary Face / Stationary Face / Elastomer / Spring / Metal Parts :
SSiC/SSiC/Spring Energized Seals/HC276/2507 Super Duplex - SSiC/SSiC/Spring Energized Seals
Place of Origin :
CHINA
Model Number :
GASPAC D
MOQ :
1pc
Packaging Details :
Carton
Supply Ability :
1000000/Month
Linear Speed :
60 m/s or less
Customization Available :
Material and dimensional customization available for specific compressor models. Contact us with your requirements.
Payment Terms :
T/T,Western Union,D/P,D/A,L/C
Mediums :
Hydrogen, methane, ethane, propane, butane, butene, pentane, carbon dioxide. For Howden Screw Compressors.
Delivery Time :
15 working days
Temperature :
-35 ~ 120 ºC
Certification :
ISO9001
Brand Name :
BESTSEAL
Pressure :
0 ~ 1.06 MPa
Description
Flowserve GASPAC D Dual Dry Gas Seal Cartridge Mechanical Seals for Howden Screw Compressors
GASPAC D

For: Howden Screw Compressors

GASPAC D Double-ended DGS for Howden Screw Compressors.

Flowserve Gaspac® Compressor Seal

Flowserve Gaspac dry gas seals incorporate non contacting lift-off technology to provide low break away torque and reliable performance under all operating conditions. The Gaspac is a standardized modular design in various configurations.

Design Parameters
  1. Compressor Inlet Pressure: 0.1 to 0.49 MPa
  2. Compressor Outlet Pressure: 0.48 to 0.795 MPa
  3. Design Pressure: 1.06 MPa
  4. Design Temperature: -35 to 120 °C
  5. Compressor Inlet Gas Temperature: -1 to 50 °C
  6. Compressor Outlet Gas Temperature: 50 to 100 °C
  7. Speed: 7527 r/min
  8. Medium: Hydrogen, methane, ethane, propane, butane, butene, pentane, carbon dioxide, etc.
Design Features
  1. Due to the high operating pressure, only explosion-proof spring energized seals with explosion-proof properties can be selected for the auxiliary sealing rings in the high-pressure section.
  2. The structural component design must undergo rigorous static analysis and optimization.
  3. The stability of the dynamic pressure effect generated by the dynamic pressure groove and the stiffness-to-leakage ratio must undergo rigorous dynamic analysis and verification tests.
  4. The isolation sealing structure requires special design and testing to ensure accurate control of compressed air consumption, thereby meeting the control requirements for the explosion limit of the secondary leakage channel.
Materials

Rotary Face / Stationary Face / Elastomer / Spring / Metal Parts

SSiC/SSiC/Spring Energized Seals/HC276/2507 Super Duplex - SSiC/SSiC/Spring Energized Seals

Model Materials GA
GASPAC D SSiC/SSiC/Spring Energized Seals/HC276/2507 Super Duplex - SSiC/SSiC/Spring Energized Seals —
Contact Us for Details
BESTSEAL — Your Reliable Partner for Mechanical Seals
BESTSEAL Advantage:
15 years Focused in mechanical seal manufacturing
3 hours Quotation response only takes 3 hours
1 day Provide production assembly drawings
1 piece MOQ, One piece can also be produced
15-20 working days The production cycle only takes 15-20 working days
real-time Real time synchronization of production progress

BESTSEAL Cartridge Mechanical Seal

Your Fast-Track Alternative to Flowserve GASPAC D

Custom Cartridge Mechanical Seals — From Drawing to Delivery in 15–20 Working Days
