Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device
Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device
Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device
Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device
Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device
Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device
Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device
Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device
Specifications
Brand Name :
HengShou
Certification :
ISO SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
$19900-39900 Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Product name :
Industrial Mesh Belt Dryer
Application :
Fruit Processing
Equipment handling :
Insulation treatment
Usable area :
50-200 square meters
Applicable materials :
Variety available
Weight :
Depend on the specific model
Description

Equipped With Nylon Drum Cleaning Device And Thermal Insulation Industrial Mesh Belt Dryer

Description:

  1. Industrial Mesh Belt Dryer equipment has strong pertinence, high practicability, applicability, energy
  2. Industrial Mesh Belt Dryer high degree of automation and intelligence: using self-controlled constant temperature device, continuous operation for 24 hours, not affected by climate, separation of water and electricity, no leakage hazard, no explosion hazard;
  3. Installation and convenience: integrated drying, dehumidification, installation, and demolition are very convenient, and can be installed indoors or outdoors.

Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
Thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation,capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device

COMPANY PROFILE

Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device

PATENT CERTIFICATE

Steel Industrial Mesh Belt Dryer Leakage Proof 16×8×3.2m With Nylon Drum Cleaning Device

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.
