400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability
400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability
400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability
400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability
400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability
400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability
400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability
400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability
Specifications
Brand Name :
HengShou
Certification :
ISO SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
$19900-39900 Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Product name :
Citrus Mesh Belt Dryer
Air supply method :
Layered air supply
Drying temperature :
50-100°
Number of mesh belts :
12-60 steel mesh belt
Description

Multifunctional Stainless Steel Door Lock Hinged Pomace Mesh Belt Dryer

Description:

  1. Citrus Mesh Belt Dryer equipment configuration is flexible, and the mesh belt washing system and material cooling system can be used.
  2. Most of the air is recycled, highly energy saving.
  3. Citrus Mesh Belt Dryer unique air distribution device makes the hot air distribution more uniform and ensures the consistency of product quality.
  4. Citrus Mesh Belt Dryer heat source can be matched with steam, heat transfer oil, electricity, or coal (oil) hot blast stove

400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
Thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation,capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability

COMPANY PROFILE

400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability

PATENT CERTIFICATE

400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

400 To 700kg/ H Citrus Mesh Belt Dryer Equipment Big Capability
