Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer
Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer
Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer
Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer
Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer
Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer
Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer
Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer
Specifications
Brand Name :
HengShou
Certification :
ISO SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
$19900-39900 Sets
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Product name :
Dehydration Mesh Belt Dryer
Heat transfer area :
Design according to production
Operation method :
Automatic continuous
Length of drying :
5-20m
Use temperature :
≤200℃
Type of work :
Steel mesh belt
Description

Air Pressure And Air Volume Can Be Adjusted Constant Temperature Dehydration Mesh Belt Dryer

Quick Detail:

  • Equipment automatic operation control
  • Air recycling, high energy saving
  • Made of high-quality stainless steel

Description:

  1. Dehydration Mesh Belt Dryer material movement is propelled by the stainless steel mesh belt to complete the entire drying process;
  2. Countercurrent conduction dehumidification to avoid reducing repeated drying procedures.
  3. Dehydration Mesh Belt Dryer are a variety of heating methods to choose from electric heating, steam heating, hot blast stove heating, and gas heating

Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
Thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation,capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer

COMPANY PROFILE

Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer

PATENT CERTIFICATE

Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

Constant Temperature Dehydration Mesh Belt Dryer Rustproof Belt Drying Machine 4Layer
