Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
Specifications
Brand Name :
HengShou
Certification :
ISO9001,ISO,SGS
Place of Origin :
Sichuan
MOQ :
1
Price :
Customize
Payment Terms :
L/C, T/T
Supply Ability :
10000 Sets Years
Delivery Time :
10 Work Days
Product Name :
Fruit drying Production Line
Installation :
Engineer support installation, video installation, drawing installation
Type :
Fully Automatic
Voltage :
380V,Customized,220V
Condition :
New
Material :
Stainless Steel
Description

Customized Length Complete Industrial Fruit Drying Production Line

Quick Detail:

  • 50 years of industry experience
  • Stainless Steel 304 Material
  • Up to 7 Heat Source Options
  • Thousands of Case Experiments
  • Support the whole industry chain
  • Multiple technical innovations
  • Automated Operation
  • Heat Recovery

Description:

The network speed, temperature, and humidity can be adjusted according to production need to meet the drying treatment of different moisture content and different types of granular materials. Energy-saving and environmental protection, no pollution in the dry explosion process, high degree of equipment automation, simple operation; strong compatibility, can effectively shorten the drying cycle and reduce processing costs.Various materials have different supporting equipment support​

Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length

Specifications:

Model DW2×6m DW2×8m DW2×10m DW2×12m DW2×14m DW2×16m
Area of dry 3 layers 29㎡ 40㎡ 51㎡ 62㎡ 73㎡ 83㎡
4 layers 39㎡ 53㎡ 68㎡ 83㎡ 97㎡ 110㎡
5 layers 48㎡ 66㎡ 85㎡ 103㎡ 121㎡ 138㎡
6layers 57㎡ 79㎡ 102㎡ 124㎡ 145㎡ 165㎡
Thickness of the material 50---150mm
Operation temperature 40---120℃
Drying time 0.5——5 hour or 3——15 hour
Motor power 1.1kw 1.5kw 1.5kw 1.5kw 2.2kw 3kw
Evaporation,capacity 200-400kg/h 300-600kg/h 400-700kg/h 500-800kg/h 600-1000kg/h 700-1200kg/h
Size of hot blast stove 1.2×2.5×1.7 1.2×2.7×1.9 1.3×3×2 1.3×3×3 1.6×3.5×2.2 1.6×3.7×2.2
Fan 8C-15kw 10C-15kw 10C-22kw 10C-37kw 12C-30kw 12C-45kw
Output conveyor 1.1kw
Total power 18kw 18.4kw 26kw 41kw 35.1kw 46.7kw

MATERIAL APPLICATION

Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length

COMPANY PROFILE

Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length

PATENT CERTIFICATE

Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length

SHIPMENT AND PACKGAGE

Packaging And Delivery Details:

1. Standard import and export wooden case

2. According to customer requirements, the packaging method can be negotiated.

Industrial Vegetable Fruit Drying Production Line ISO9001 AC220V Customized Length
