Specifications
Brand Name :
BANNER
Model Number :
QS18VP6LLPQ8
Certification :
ATEX
Place of Origin :
US
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,XT,ALIPAY
Supply Ability :
100pcs per month
Delivery Time :
Negotiable
Packaging Details :
carton
Power Supply :
1
Ambient Temperature :
-
Electrical Rating :
G
Certifications :
S
Description

Banner QS18VP6LLPQ8 Laser Sensor | 10m Range, PNP, M18, IP67

Banner QS18VP6LLPQ8 polarized retroreflective laser sensor specifications. 0.1-10m range, PNP output, 10-30V DC, M18 threaded barrel, IP67.

Product Overview

The Banner QS18VP6LLPQ8 is an M18 cylindrical polarized retroreflective laser sensor​ designed for precise detection of small objects. It features a visible red Class 1 laser with a narrow beam for accurate long-range sensing up to 10m. The sensor incorporates a polarized filter to reject false signals from shiny surfaces and offers PNP output with Light/Dark operate modes. Housed in an ABS thermoplastic body with IP67 rating, it is suitable for demanding industrial automation environments.

Technical Specifications (Electrical & Sensing)

Parameter

Specification

Manufacturer​

Banner Engineering

Series​

QS18 (World-BEAM)

Model​

QS18VP6LLPQ8

Sensing Mode​

Polarized Retroreflective

Sensing Range​

0.1 m to 10 m (with reflector)

Light Source​

Visible Red Laser, Class 1 (650 nm)

Supply Voltage​

10 to 30 V DC (±10% ripple)

Output Type​

PNP (Complementary SPDT solid-state)

Max. Load Current​

100 mA

Response Time​

≤ 700 μs (ON/OFF)

Technical Specifications (Mechanical & Environmental)

Parameter

Specification

Housing Style​

Cylindrical, M18 x 1 mm Threaded Barrel

Housing Material​

ABS Thermoplastic

Connection​

4-pin M12 Quick-Disconnect (Euro Style)

Protection Rating​

IP67, NEMA 6P

Operating Temperature​

-10 °C to +50 °C

Ambient Light Immunity​

10,000 lux (typical)

Adjustment​

Potentiometer for sensitivity

Indicators​

Green Power LED, Amber Status LED

Key Features

  • Polarized Laser Technology:​ Reduces false triggers from reflective surfaces like metal or plastic.

  • Long-Range Precision:​ 10m detection range with a narrow beam for small object sensing.

  • Fast Response:​ 700μs response time for high-speed automation applications.

  • Rugged Construction:​ IP67-rated housing resistant to water and dust ingress.

  • Easy Wiring:​ Standard 4-pin M12 connector for quick installation.

Applications

  • Small part detection on conveyors

  • Object positioning in packaging machinery

  • Web break detection in material handling

  • Pallet presence sensing in logistics
