Phoenix Contact PLC-RSC-24UC/21 | 24V DC Interface Relay, 1 CO, 6A
Phoenix Contact PLC-RSC-24UC/21 | 24V DC Interface Relay, 1 CO, 6A
Phoenix Contact PLC-RSC-24UC/21 | 24V DC Interface Relay, 1 CO, 6A
Phoenix Contact PLC-RSC-24UC/21 | 24V DC Interface Relay, 1 CO, 6A
Phoenix Contact PLC-RSC-24UC/21 | 24V DC Interface Relay, 1 CO, 6A
Phoenix Contact PLC-RSC-24UC/21 | 24V DC Interface Relay, 1 CO, 6A
Specifications
Brand Name :
Phoenix Contact
Model Number :
PLC-RSC-24UC21
Certification :
ATEX
Place of Origin :
DE
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,XT,ALIPAY
Supply Ability :
100pcs per month
Delivery Time :
Negotiable
Packaging Details :
carton
Power Supply :
1
Ambient Temperature :
-
Electrical Rating :
G
Certifications :
S
Description

Phoenix Contact PLC-RSC-24UC/21 | 24V DC Interface Relay, 1 CO, 6A

Phoenix Contact PLC-RSC-24UC/21 pluggable relay interface module. 24V AC/DC coil, 1 Changeover contact (1 CO), 6A switching current, 6.2mm width, DIN rail mount.

Product Overview

The Phoenix Contact PLC-RSC-24UC/21​ is a plug-in relay interface module​ from the PLC-INTERFACE​ family. It consists of a PLC-BSC.../21 base terminal​ and a pluggable miniature relay with 1 Changeover (CO) contact. Designed for signal amplification and isolation between controllers (PLCs) and actuators, it operates on a 24V AC/DC supply​ and features a compact 6.2 mm width​ for high-density DIN rail mounting. The module includes a yellow LED status indicator and offers reliable switching for industrial control circuits.

Technical Specifications (Electrical)

Parameter

Specification

Product Family​

PLC-INTERFACE

Order Number​

PLC-RSC-24UC/21​ (Base: 2966278)

Rated Supply Voltage​

24 V AC / 24 V DC​

Supply Voltage Range​

19.4 ... 33.6 V AC/DC

Typ. Current Consumption​

8.5 mA (at 24 V DC)

Contact Configuration​

1 Changeover (1 CO)​

Max. Switching Voltage​

250 V AC / 250 V DC

Max. Switching Current​

6 A​ (Resistive Load)

Contact Material​

AgSnO (Gold-plated)

Isolation (Coil/Contacts)​

4 kV AC

Technical Specifications (Mechanical & Environmental)

Parameter

Specification

Mounting​

DIN Rail (35 mm)

Dimensions (W x H x D)​

6.2 x 80 x 94 mm​

Connection​

Screw Terminal (Plug-in Base)

Wire Cross-Section​

0.14 ... 2.5 mm²

Operating Temperature​

-40 °C ... +60 °C​

Protection Rating​

IP20

Mechanical Life​

20 million operations

Housing Material​

Gray (RAL 7042), UL 94 V-0

Key Features

  • Space-Saving Design:​ Ultra-slim 6.2 mm width allows maximum utilization of control cabinet space.

  • Pluggable Design:​ Relay cartridge is pluggable, enabling fast replacement without rewiring the base terminal.

  • Wide Voltage Input:​ Compatible with both 24V AC and DC control signals, providing flexibility in system design.

Applications

  • Signal amplification and isolation for PLC digital outputs

  • Interface between low-power control circuits and high-power loads (contactors, solenoids)

  • General-purpose switching in industrial automation cabinets
