Schneider Electric BMH0701P01A2A | Lexium 32 70mm Servo Motor 1.2Nm 8000rpm
Schneider Electric BMH0701P01A2A | Lexium 32 70mm Servo Motor 1.2Nm 8000rpm
Schneider Electric BMH0701P01A2A | Lexium 32 70mm Servo Motor 1.2Nm 8000rpm
Schneider Electric BMH0701P01A2A | Lexium 32 70mm Servo Motor 1.2Nm 8000rpm
Specifications
Brand Name :
Schneider Electric
Model Number :
BMH0701P01A2A
Certification :
ATEX
Place of Origin :
DE
MOQ :
1
Price :
Negotiable
Payment Terms :
T/T,XT,ALIPAY
Supply Ability :
100pcs per month
Delivery Time :
Negotiable
Packaging Details :
carton
Power Supply :
1
Ambient Temperature :
-
Electrical Rating :
G
Certifications :
S
Description

Schneider Electric BMH0701P01A2A | Lexium 32 70mm Servo Motor 1.2Nm 8000rpm

Schneider Electric BMH0701P01A2A servo motor. 70mm flange, 1.2Nm continuous torque, 8000rpm max speed, SinCos Hiperface encoder. IP54 rated for Lexium 32 drives.

Product Overview

The Schneider Electric BMH0701P01A2A​ is a 70mm flange synchronous servo motor​ from the Lexium 32 (BMH series)​ family. It delivers a continuous stall torque of 1.2 Nm​ with a maximum speed of 8000 rpm. This variant features a smooth shaft (no keyway), IP54 protection​ for dust and water resistance, and a high-resolution single-turn SinCos Hiperface encoder​ (131,072 points/turn). It is designed for direct integration with Lexium 32 servo drives for precise motion control in industrial automation.

Technical Specifications (Electrical & Performance)

Parameter

Specification

Manufacturer / Series​

Schneider Electric / Lexium 32 (BMH)

Model Number​

BMH0701P01A2A

Product Type​

3-Phase Synchronous Servo Motor

Rated Voltage​

400 – 480 V AC​ (3-phase)

Continuous Stall Torque​

1.2 Nm​

Peak Torque​

4.2 Nm​

Rated Speed​

3000 / 5000 rpm (drive dependent)

Max. Mechanical Speed​

8000 rpm​

Rated Power​

350 W / 700 W (drive dependent)

Encoder Type​

Single-turn SinCos Hiperface​

Encoder Resolution​

131,072 points/turn​

Technical Specifications (Mechanical & Environmental)

Parameter

Specification

Flange Size​

70 mm​ (IEC standard)

Shaft Type​

Smooth (Untapped, No Keyway)​

Shaft Diameter​

11 mm​

Shaft Length​

23 mm

Holding Brake​

Without Brake​

IP Rating​

IP54​

Electrical Connection​

Rotatable Right-Angle Connector

Mounting​

4x M5 threaded holes (Ø82mm PCD)

Rotor Inertia​

0.59 kg·cm²

Weight​

Approx. 1.6 kg

Operating Temperature​

0 °C to +40 °C (ambient)

Key Features

  • High Dynamic Response:​ 10-pole motor design with low rotor inertia (0.59 kg·cm²) for rapid acceleration.

  • High-Resolution Feedback:​ SinCos Hiperface encoder provides precise position feedback for closed-loop control.

  • IP54 Protection:​ Suitable for use in environments with dust and limited water exposure.

  • Lexium 32 Compatibility:​ Optimized for use with Schneider Electric Lexium 32 series servo drives.

Applications

  • Precision CNC machinery and robotics

  • Packaging and material handling equipment

  • Automated assembly and pick-and-place systems
