Phoenix Contact QUINT4-PS/1AC/2X15DC/2/PT | ±15V DC Dual Output DIN Rail Power Supply
Phoenix Contact QUINT4-PS/1AC/2X15DC/2/PT | ±15V DC Dual Output DIN Rail Power Supply
Phoenix Contact QUINT4-PS/1AC/2X15DC/2/PT | ±15V DC Dual Output DIN Rail Power Supply
Phoenix Contact QUINT4-PS/1AC/2X15DC/2/PT | ±15V DC Dual Output DIN Rail Power Supply
Specifications
Power Supply :
1
Ambient Temperature :
-
Model Number :
QUINT4-PS1AC2X15DC2PT
Certification :
ATEX
MOQ :
1
Place of Origin :
VN
Price :
Negotiable
Payment Terms :
T/T,XT,ALIPAY
Supply Ability :
100pcs per month
Delivery Time :
Negotiable
Packaging Details :
carton
Electrical Rating :
G
Brand Name :
Phoenix Contact
Certifications :
S
Description

Phoenix Contact QUINT4-PS/1AC/2X15DC/2/PT | ±15V DC Dual Output DIN Rail Power Supply

Phoenix Contact QUINT4-PS/1AC/2X15DC/2/PT industrial power supply. 100-240V AC input, dual ±15V DC outputs (2A / 1.4A), 45mm DIN rail mount with push-in connection.

Product Overview

The Phoenix Contact QUINT4-PS/1AC/2X15DC/2/PT​ (Order No. 2904596) is a compact dual-output industrial power supply​ from the QUINT POWER series. It converts a wide-range 100-240V AC input​ into regulated ±15V DC outputs​ (+15V/2A and -15V/1.4A), commonly used for powering op-amp circuits, analog instrumentation, and industrial controllers. The unit features push-in spring-clamp terminals​ for fast wiring and includes comprehensive monitoring via a 5-pin signal contact.

Technical Specifications (Electrical)

Parameter

Specification

Order Number​

2904596​

Input Voltage​

100 ... 240 V AC​ (50/60 Hz)
110 ... 250 V DC

Output Voltage​

+15 V DC​ / -15 V DC​

Rated Current​

+15V: 2 A
-15V: 1.4 A​

Static Boost Current​

2.5 A (+15V, ≤40°C)

Dynamic Boost Current​

4.0 A (+15V, ≤60°C, 5s)

Ripple & Noise​

< 60 mVpp

Efficiency​

Up to 89.4%

Regulation Accuracy​

< ±0.5% (load), < ±0.1% (line)

Protections​

OVP (≤18V), Short Circuit, Overload

Technical Specifications (Mechanical & System)

Parameter

Specification

Connection Type​

Push-in Spring Clamp​ (0.2-2.5 mm²)

Mounting​

DIN Rail (35 mm)

Dimensions (WxHxD)​

45 mm x 106 mm x 90 mm​

Operating Temperature​

-25 °C ... +70 °C​

Storage Temperature​

-40 °C ... +85 °C

Signal Contact​

5-pin (Ready, Power Good, Remote Sense)

Isolation​

Input/Output 4 kV AC

MTTF​

~1,284,000 hours (25°C)

IP Rating​

IP20 (DIN rail mounted)

Key Features

  • Dual Symmetric Output:​ Provides both positive (+15V) and negative (-15V) rails for analog and control circuits.

  • Ultra-Wide Input Range:​ Operates from 100V to 240V AC without manual tapping.

  • High Power Density:​ 45mm width saves space in control cabinets.

  • Diagnostic Ready:​ Integrated signal contact provides remote monitoring of output status.

Applications

  • Power supply for operational amplifiers and analog signal conditioning circuits

  • Industrial PC and controller auxiliary power

  • Test and measurement equipment in control panels
