Eaton 9SX1500 | 1500VA / 1350W Online UPS | 9SX Series

Eaton 9SX1500 online double-conversion UPS. 1500VA / 1350W capacity, pure sine wave output, tower/rack-mountable, hot-swappable batteries, for server and industrial backup.

Product Overview

The Eaton 9SX1500​ is an online double-conversion UPS​ from the 9SX series​ with a rated capacity of 1500VA / 1350W. It provides true online power protection with zero transfer time, making it suitable for servers, network equipment, and industrial automation systems. This model features a graphical LCD display, hot-swappable battery modules, and supports optional external battery packs (EBMs) for extended runtime.

Technical Specifications (Electrical & Performance)

Technical Specifications (Mechanical & Environmental)

Key Features

• True Online Protection:​ Double-conversion technology provides complete isolation from grid noise, spikes, and frequency variations, ensuring clean power for sensitive electronics.

• Extended Runtime Capability:​ Supports connection of up to 4 External Battery Modules (EBMs)​ to significantly increase backup time for critical applications.

• Advanced Battery Management (ABM):​ Three-stage charging technology extends battery life and includes automatic self-test and temperature compensation.

• Flexible Monitoring:​ Equipped with a graphical LCD interface and multiple communication ports (USB, RS-232, dry contacts) for integration with monitoring software and building management systems.

Applications

• Server & IT Infrastructure:​ Protecting data centers, server rooms, and network closets from power outages and disturbances.

• Industrial Automation:​ Providing backup power for PLCs, DCS systems, and process control equipment in manufacturing environments.

• Critical Systems:​ Ensuring uninterrupted operation for security systems, medical devices, and communication equipment.
