Q355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion Prevention
Q355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion Prevention
Specifications
Brand Name :
Zhonghai Bailey Bridge
Model Number :
CB200/CB321
Certification :
IS09001, CE
Place of Origin :
China
MOQ :
1 Pcs
Price :
USD 95-450
Payment Terms :
L/C,D/P,T/T
Supply Ability :
60000ton/year
Delivery Time :
8-10 work days
Packaging Details :
Naked
Product Capability :
60000 Pieces Per Year
Grade :
Q355B
Material :
Steel
Corrosion Prevention :
Galvanization Or Painting
Antisepsis :
galvanize
Certificates :
ISO9001: 2000 and API 5DP
Surface :
pained
Width :
4.2m & 7.35m ,10.5m
Description

Bridge Steel Pipe/steel Pipe Bridge For Sale


Jiangsu Zhonghai Bridge Equipment Co., Ltd. specializes in the design, manufacture, and installation of a wide range of bridge equipment, with a particular focus on prefabricated highway steel bridges and Bailey bridges. These bridges are widely used in various engineering fields, including national defense, flood control, emergency response, transportation, water conservancy, railways, and more. The company's core products are manufactured according to the "Technical Specification for Construction of Highway Bridges and Culverts" (JTJ041—2008) issued by the Ministry of Transport. Additionally, they offer related products such as Bailey bridge accessories, steel supports, and other structural components.



Specifications:

​

CB200 Truss Press Limited Table
NO. Internal Force Structure Form
Not Reinforced Model Reinforced Model
SS DS TS QS SSR DSR TSR QSR
200 Standard Truss Moment(kN.m) 1034.3 2027.2 2978.8 3930.3 2165.4 4244.2 6236.4 8228.6
200 Standard Truss Shear (kN) 222.1 435.3 639.6 843.9 222.1 435.3 639.6 843.9
201 High Bending Truss Moment(kN.m) 1593.2 3122.8 4585.5 6054.3 3335.8 6538.2 9607.1 12676.1
202 High Bending Truss Shear(kN) 348 696 1044 1392 348 696 1044 1392
203 Shear Force of Super High Shear Truss(kN) 509.8 999.2 1468.2 1937.2 509.8 999.2 1468.2 1937.2
Q355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion PreventionQ355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion PreventionQ355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion PreventionQ355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion Prevention

​​

CB200 Table of Geometric Characteristics of Truss Bridge(Half Bridge)
Structure Geometric Characteristics
Geometric Characteristics Chord Area(cm2) Section Properties(cm3) Moment of Inertia(cm4)
ss SS 25.48 5437 580174
SSR 50.96 10875 1160348
DS DS 50.96 10875 1160348
DSR1 76.44 16312 1740522
DSR2 101.92 21750 2320696
TS TS 76.44 16312 1740522
TSR2 127.4 27185 2900870
TSR3 152.88 32625 3481044
QS QS 101.92 21750 2320696
QSR3 178.36 38059 4061218
QSR4 203.84 43500 4641392
Q355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion PreventionQ355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion PreventionQ355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion PreventionQ355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion Prevention

​​

CB321(100) Truss Press Limited Table
No. Lnternal Force Structure Form
Not Reinforced Model Reinforced Model
SS DS TS DDR SSR DSR TSR DDR
321(100) Standard Truss Moment(kN.m) 788.2 1576.4 2246.4 3265.4 1687.5 3375 4809.4 6750
321(100) Standard Truss Shear (kN) 245.2 490.5 698.9 490.5 245.2 490.5 698.9 490.5
321 (100) Table of geometric characteristics of truss bridge(Half bridge)
Type No. Geometric Characteristics Structure Form
Not Reinforced Model Reinforced Model
SS DS TS DDR SSR DSR TSR DDR
321(100) Section properties(cm3) 3578.5 7157.1 10735.6 14817.9 7699.1 15398.3 23097.4 30641.7
321(100) Moment of inertia(cm4) 250497.2 500994.4 751491.6 2148588.8 577434.4 1154868.8 1732303.2 4596255.2
Q355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion PreventionQ355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion PreventionQ355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion PreventionQ355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion Prevention

​


Advantage

Possessing the features of simple structure,
convenient transport, speedy erection
easy disassembling,
heavy loading capacity,
great stability and long fatigue life
being capable of an alternative span, loading capacity


Q355B Pipe Steel Truss Bridge Galvanization Or Painting Corrosion Prevention
