Rewinding Coding Machine with Triple-Servo Drive and High-Precision UV Laser for Adjustable-Length Roll Material Marking
Rewinding Coding Machine with Triple-Servo Drive and High-Precision UV Laser for Adjustable-Length Roll Material Marking
Specifications
After Service :
On-line or video technical support
Label Size :
L(20-280)mm H 30-144mm
Place of Origin :
CHINA
Certification :
VERIFICATION OF CONFORMITY
Condition :
New
Payment Terms :
T/T
Labelingspeed :
200-400 labels per minute
Brand Name :
ZHIROBO
Capacity :
50-200b/min
MOQ :
1 set
Applicable Label Size :
standard model width: 5mm～45mm;
Price :
Negotiable
Material Size :
20-100mm H 40-200mm
Delivery Time :
15-30 working days
Model Number :
ZRD-220
Transport Package :
Wood
Description
Rewinding Coding Machine ZRD-220
Product Overview

This machine integrates professional laser marking and material rewinding, ideal for processing various film and roll materials. It delivers stable, high-precision results and effectively boosts productivity in modern industrial production.

Key Features
  • User-friendly touch control interface with programmable system for quick and flexible parameter adjustment
    Triple servo configuration maintains consistent tension control for unwinding and rewinding processes
    Precise material feeding with customizable length and reliable positioning control
    High-efficiency water-cooled UV laser module delivers clear, durable and long-lasting marking effects
    Adjustable marking quantity to adapt to diverse production demands
    Intuitive operation, automatic fault diagnosis, and intelligent one-key operation for simplified use
Main Technical Parameters
Parameter Specification
Model ZRD-220 Rewinding Coding Machine
Material Width 50-220mm
Material Diameter Max outer diameter: 245mm (core diameter: 76mm)
Coding Speed Depends on coding requirements
Mechanical Allowable Speed 0-30m/min
Laser Type 10W UV Laser (355nm)
Voltage and Power AC220V 2.6KW
Air Pressure 0.5mpa
Machine Dimensions 1620mm*1380mm*1750mm
Net Weight 1600KG
Configuration Parameters
Component Specification
Touch Screen HMI
Servo Roll Feed HCFA
Roll Feeding Driver HCFA
Fixed-length Servo HCFA
Fixed-length Driver HCFA
Rewinding Servo HCFA
Rewinding Driver HCFA
Laser Coding Machine KEXIN
Laser Galvo Scanner KEXIN
Reducer Smart
Detection Fiber KEYENCE
PLC HCFA
Air Switch CHINT
Switching Power Supply MEAN WELL
Deviation Correction Youdao
Relay IDEC
Push Button Switch Schneider
Cylinder XINGCHEN
Filter STNC
Solenoid Valve STNC
Magnetic Switch AirTAC
Bearing NSK
Frame Imported Powder Coating
Motion Controller HCFA
Photoelectric Sensor Boyee
Guide Rail HIWIN
Equipment Layout
Rewinding Coding Machine with Triple-Servo Drive and High-Precision UV Laser for Adjustable-Length Roll Material Marking
Product Images
Rewinding Coding Machine with Triple-Servo Drive and High-Precision UV Laser for Adjustable-Length Roll Material Marking
Rewinding Coding Machine with Triple-Servo Drive and High-Precision UV Laser for Adjustable-Length Roll Material Marking
Rewinding Coding Machine with Triple-Servo Drive and High-Precision UV Laser for Adjustable-Length Roll Material Marking
