Two Side Automatic Labeling Machine 220V 50HZ Bottle Sticker Labelling Machine 6000 Bottles Per Hour Output
Two Side Automatic Labeling Machine 220V 50HZ Bottle Sticker Labelling Machine 6000 Bottles Per Hour Output
Specifications
Place of Origin :
CHINA
Transport Package :
Wood
Printer :
date code printer (optional)
Model No :
NP-RL
Payment Terms :
T/T
Roll Inside :
Diameter 76mm
Delivery Time :
15-30 working days
Max Labeling Output :
6000 bottles per hour
Power Voltage :
220V 50HZ
Label Length :
8 ~ 150mm
Certification :
VERIFICATION OF CONFORMITY
Maximum Label Length :
500mm
MOQ :
1 set
Brand Name :
ZHIROBO
Air Pressure :
0.4～0.6Mpa
Labeling Head :
2 sides labeling
Model Number :
ZRD-220
Price :
Negotiable
Name :
Automatic Labeling Machine
Description
Automatic Labeling Machine with 6000 bottles per hour output and 2 sides labeling for food beverage and pharma packaging at 220V 50HZ
Basic Use

Mainly used for laser coding and rewinding of various coiled materials.Ideal for high‑precision laser coding, marking, and rewinding operations across a wide range of coiled materials including films, tapes, labels, packaging membranes, and other web‑based products, delivering stable and efficient processing for industrial production lines.

Equipment Advantages
  • Intuitive control panel supported by programmable microcomputer system for flexible parameter setting
    Triple servo system ensures stable tension control for both unwinding and rewinding, with adjustable film feeding length via precise servo positioning
    High-precision water-cooled UV laser module delivers clear and consistent marking performance
    Customizable number of codes to match diverse production requirements
    Simple operation, automatic fault warning system, and intelligent one‑key operation for easy use.
  • Equipment Layout

Two Side Automatic Labeling Machine 220V 50HZ Bottle Sticker Labelling Machine 6000 Bottles Per Hour Output

Main Technical Parameters
Model ZRD-220 Rewinding Coding Machine
Material Width 50-220mm
Material Diameter Max outer diameter: 245mm (core diameter: 76mm)
Coding Speed Depends on coding requirements
Mechanical Allowable Speed 0-30m/min
Laser Type 10W UV Laser (355nm)
Voltage and Power AC220V 2.6KW
Air Pressure 0.5mpa
Machine Dimensions 1620mm*1380mm*1750mm
Net Weight 1600KG
Configuration Parameters
Model Rewinding Coding Machine ZRD-220
Touch Screen HMI
Servo Roll Feed HCFA
Roll Feeding Driver HCFA
Fixed-length Servo HCFA
Fixed-length Driver HCFA
Rewinding Servo HCFA
Rewinding Driver HCFA
Laser Coding Machine KEXIN
Laser Galvo Scanner KEXIN
Reducer Smart
Detection Fiber KEYENCE
PLC HCFA
Air Switch CHINT
Switching Power Supply MEAN WELL
Deviation Correction Youdao
Relay IDEC
Push Button Switch Schneider
Cylinder XINGCHEN
Filter STNC
Solenoid Valve STNC
Magnetic Switch AirTAC
Bearing NSK
Frame Imported Powder Coating
Motion Controller HCFA
Photoelectric Sensor Boyee
Guide Rail HIWIN
