Specifications
Model Number :
HD-390C
Brand Name :
imhoo
Place of Origin :
Jiangsu, China
MOQ :
1 piece
Price :
$7.70-9.30 / piece
Measuring Current Range :
0.1-250mA
Measuring Voltage Range :
0.25-1000v
Dimensions :
160*105*40mm
Measuring Capacitance Range :
/
Measuring Inductance Range :
/
Measuring Resistance Range :
0.1Ω-20MΩ
Operating Temperature :
0-40℃
color :
red,blue
transistor test :
yes
continuity buzzer test :
yes
decibel test :
yes
Description
Analog Multimeter Universal Meter Pointer Display Electrical Tester AC DC Voltage Current Resistance With Test Pen Buzzer
Professional pointer display electrical tester for AC/DC voltage, current, and resistance measurements with built-in buzzer and test pens.
Universal Meter Pointer Display Electrical Tester AC DC Voltage Current Resistance
Universal Meter Pointer Display Electrical Tester AC DC Voltage Current Resistance
Universal Meter Pointer Display Electrical Tester AC DC Voltage Current Resistance
Universal Meter Pointer Display Electrical Tester AC DC Voltage Current Resistance
Key Features & Specifications
Universal Meter Pointer Display Electrical Tester AC DC Voltage Current Resistance
Measurement Capabilities
  • 22 test ranges across 8 working functions
  • DC Voltage Range (±3.0% F.S.): 0.25/2.5/10/50/250/1000V
  • AC Voltage Range (±4.0% F.S.): 10/50/250/1000V
  • DC Current Range (±3.0% F.S.): 0.1/2.5/25/250mA, 10A (±4.0% F.S.) without 10A fuse
  • Resistance Range (0.1Ω~20MΩ, ±3.0% of Arc): x1, x10, x100, x1K, x10K
  • Dry Battery Check: 1.5V, 9V
  • Continuity testing with audible buzzer
  • Transistor hFE check via front panel jack
  • Decibel Test: -20~+62dB with external capacitor
Technical Specifications
  • High Input Impedance: 10KΩ/V DCV and 4.5 KΩ/V ACV
  • Enhanced overload protection with fast-acting 0.5A/250V fuse
  • Heavy-duty ABS plastic housing with protective holster
  • Adjustable back tilt stand with hook-up design
  • Dimensions: 160×105×40mm
  • Weight: Approximately 320g
  • Power Supply: 6F22 9V dry battery (1pc) and AA size 1.5V battery (1pc)
Packaging Information
Packing Type White Box
Carton Size 53×38×32cm
Standard Packing per Carton 32 pieces
Net Weight 18kg
Gross Weight 19kg
