0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V
0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V
0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V
0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V
0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V
0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V
Specifications
Model Number :
HD-390D
Brand Name :
imhoo
Place of Origin :
Jiangsu, China
MOQ :
1 piece
Price :
$13.50-14.90 / piece
Measuring Current Range :
0.05-250mA,10A
Measuring Voltage Range :
0.05-500v(1000v)
Dimensions :
160*105*40mm
Measuring Capacitance Range :
NULL
Measuring Inductance Range :
NULL
Measuring Resistance Range :
NULL
Operating Temperature :
0-40℃
color :
red,orange
transistor test :
yes
continuity buzzer test :
yes
decibel test :
yes
leakage current and diode test :
yes
style :
fashion
packing :
box
working function :
11 kinds
various test range :
yes
Description
Analog Multimeter - Professional Electrical Testing Instrument
Cheap Analog Multimeter Analog Multimeter Factory
High-quality analog multimeter designed for accurate electrical measurements with comprehensive protection features.
0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V 0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V 0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V 0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V 0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V 0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V
Key Features
  • Strong magnet pivot-jewel movement mechanism
  • 25 test ranges with 11 working functions
  • Perfect overload protection with two fast-acting fuses (0.5A & 10A)
  • Adjustable back tilt stand with hook-up design
  • Compact soft protective holster included
  • Super input impedance: 20KΩ at all ACV & DCV ranges
  • Auto power-off after 15 minutes, restores when turned to "off"
  • Mode button for DC to AC range switching
  • Dry battery check: 1.5V, 9V
  • Continuity buzzer testing
  • Leakage current & diode test
  • Transistor test via test leads
  • Over-voltage category CAT III 500V, CAT II 1000V
0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V
Technical Specifications
Measurement Type Range Accuracy
AC/DC Voltage 0.05/0.5/2.5/10/50/250/500V(1000V) ±3.0% F.S.
AC/DC Current 0.05/0.25/205/25/250mA, 10A ±4.0% F.S.
Resistance 0.1/0.5/2.5/10/50/250/500V ±3.0% of Arc
Additional Specifications
  • Decibels Test: -20~+62dB via test leads with external Polyester capacitor 0.047uF/400V
  • Dimensions: 160×105×40mm
  • Weight: 470g approximately
  • Power Supply: 6F22 9V 1pc, AA size 1.5V 2pcs
  • Super Input Impedance: 20KΩ at all ranges of ACV & DCV
Packaging Information
Packing Type White Box
Carton Size 53×38×32cm
Standard Packing per Carton 32pcs
Net Weight 18kg
Gross Weight 19kg
0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V 0.05-250mA 10A Measuring Current Range Analog Multimeter 0.05-500V
