Specifications
Model Number :
472
Brand Name :
Imhoo
Place of Origin :
Jiangsu, China
MOQ :
200 pieces
Price :
$5.19-6.50 / piece
Measuring Current Range :
50uA~250mA
Measuring Voltage Range :
0.1~1000V
Dimensions :
1650x100x36mm
Measuring Capacitance Range :
100pF~2000uF
Measuring Inductance Range :
/
Measuring Resistance Range :
1~10KΩ
Operating Temperature :
10~40℃
color :
blue
Description
472C Analogue Multimeter Analog Meter

Professional analogue multimeter designed for accurate electrical measurements with comprehensive testing capabilities.

Key Features
  • Transistor & LED Test Functionality
  • Continuity Test With Audible Buzzer
Technical Specifications
Measurement Type Ranges Accuracy
Capacitance Test 100pF~0.025uF/2.5uF/25uF .2000uF ±3.0F.S.
DC Voltage 100m/500m/2.5/10/50/250/1000v(20kΩ/V)
25kV(with Hvprobe)		 ±3.0F.S.
AC Voltage 10/50/250/1000v(9kΩ/V) ±4%f.s.
DC Current 50μ/2.5m/25m/250mA
2.5A,10A		 ±3%f.s.
±5%f.s.
Resistance 2/20k/200k/2M/20mΩ ±3% of arc.
NULL ±5V/±25V ±5%f.s.
dB -10-62dB -
Ll 150μ/1.5m/15m/150mA -
hFE 0-1000(w/TR connector) -
Battery Test 1.5V -
Power Supply R6(1.5V)X2,6F22(9V)X1 -
Dimensions 150×100×36mm -
Weight 280g -
