Bakelite Material 60.7 X 71mm Analog Panel DC Voltmeter For DC Voltage Measurement
Bakelite Material 60.7 X 71mm Analog Panel DC Voltmeter For DC Voltage Measurement
Bakelite Material 60.7 X 71mm Analog Panel DC Voltmeter For DC Voltage Measurement
Bakelite Material 60.7 X 71mm Analog Panel DC Voltmeter For DC Voltage Measurement
Bakelite Material 60.7 X 71mm Analog Panel DC Voltmeter For DC Voltage Measurement
Bakelite Material 60.7 X 71mm Analog Panel DC Voltmeter For DC Voltage Measurement
Bakelite Material 60.7 X 71mm Analog Panel DC Voltmeter For DC Voltage Measurement
Bakelite Material 60.7 X 71mm Analog Panel DC Voltmeter For DC Voltage Measurement
Specifications
Model Number :
TP-670
Brand Name :
ymiho
Place of Origin :
Wuxi, China
MOQ :
100
Price :
$1-5 / piece
Accuracy Class :
2.5
Measuring Range :
According to Customer
Dimensions :
60.7x71mm
Display Type :
Analog Only
Operating Temperature :
-20-50℃
Material :
Bakelite
Packaging Details :
carton packaging
Delivery Time :
15 work days
Description
Analog DC Panel Voltmeter 670
High-quality analog panel voltmeter designed for precise DC voltage measurement applications in industrial and electrical systems.
Bakelite Material 60.7 X 71mm Analog Panel DC Voltmeter For DC Voltage Measurement
Construction & Materials
  • Case Material: PMMA plastic for external case with non-combustible ABS plastic base
  • Alternative Option: Non-combustible PC plastic available for both case and base
  • Temperature Resistance: Maintains structural integrity at 70°C (PMMA/ABS) and 120°C (PC)
Customization Options
IMHOO offers comprehensive OEM services including custom ranges, changeable scales, waterproof designs, and other specialized modifications to meet specific application requirements.
Ammeter Specifications
Type AC Ranges DC Ranges
Microamperes (μA) 50μA, 100μA, 150μA, 500μA 50μA, 100μA, 150μA, 500μA
Milliamperes (mA) 1mA, 2mA, 5mA, 10mA, 20mA, 30mA, 50mA, 75mA, 100mA, 150mA, 200mA, 250mA, 300mA, 500mA 1mA, 2mA, 5mA, 10mA, 20mA, 30mA, 50mA, 75mA, 100mA, 150mA, 200mA, 250mA, 300mA, 500mA
Amperes (A) 1A, 2A, 3A, 7.5A, 10A, 20A, 30A, 50A 1A, 2A, 3A, 7.5A, 10A, 20A, 30A, 50A
With External CT/Shunt X1A: 10/1A to 1000/1A and custom ranges
X5A: 10/5A to 1000/5A and custom ranges		 50mV, 60mV, 75mV: 10A to 3000A ranges
Voltmeter Specifications
Type AC Voltage Ranges DC Voltage Ranges
Voltage (V) 50mV to 600V (multiple standard ranges) 50mV to 600V (multiple standard ranges)
Bakelite Material 60.7 X 71mm Analog Panel DC Voltmeter For DC Voltage Measurement
