Specifications
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Construction works , Energy & Mining
Welding Mode :
VERTICAL/HORIZONTAL
MOQ :
1 set
Warranty of core components :
1 Year
Brand Name :
Xingweihan
Welding Area :
Spot Area
MOQ :
1 Set
Core Components :
PLC, Motor, Pressure Vessel
Price :
$10,000-15,000 / set
Place of Origin :
Sichuan, China
dimensions :
CUSTOMIZED
weight (kg) :
500 KG
Product Name :
Machines manufacturer pedal mini metal welding machine
Video outgoing-inspection :
Provided
voltage :
380V
After-sales Service Provided :
Overseas third-party support available
Certification :
CCC
Color :
Green/Yellow
Machinery Test Report :
Provided
Marketing Type :
New Product 2020
forming time :
1s-10s Adjustable
usage :
Seam Welding Machine
welding diameter :
DEPEND
warranty :
12 Months
Application :
Welding Soldering
Feature :
Portable Welding
Type :
Sheet Metal Spot Welder
condition :
New
Function :
Spot welding
Showroom Location :
Philippines, Brazil, India, Thailand
Description
Chinese Rolling Seam welding machine with automatic feeding system 2018
Chinese Rolling Seam Welding Machine with Automatic Feeding System 2018
Product Description

"ALL SPOT WELDING MACHINE CAN BE CUSTOMIZED."

FEATURES:

Item

UNIT

FN-40

FN-80-H

FN-100-H

FN-160-H

FN-100-E

FN-160-E

Rated power

KVA

40

80

100

160

100

160

Voltage input

V

380

380

380

380

380

380

Frequency

Hz

50Hz

50

50

50

50

50

Max. short circuit current

KA

26

30

40

30

40

Working Stroke

mm

100

100

100

100

100

Welding Efficinecy

m/min

0.7-3.9

0.7-3.9

0.7-3.9

0.7-3.9

0.7-3.9

Max. Force

N

6000

6000

7800

6000

7800

Max. Welding Capacity

mm

1.2+1.2

1.5+1.5

2.0+2.0

1.5+1.5

2.0+2.0

Motor Power

W

550

750

750

750

400

Cooling Consumption

L/min

8

8

10

8

10

Weight

Kg

380

510

630

530

700

ADVANTAGES:

1,Stable and easy to adjust.

2,Internal cooling used in the welder, while external cooling of the welding wheel.

3,The rotating part is embedded silver tile structure, the conductive seat is fully sealed and lubricating.

4,Two kinds of welding modes: Horizontal and Vertical.

USAGE:

Widely used in hardware fittings, electrical, automobile, fuel tank and other manufacturing industries industry.
