Specifications
Product name :
Automatic Piston Bore Shock Absorber Seam Welders For Steel
Type :
Horizontal Seam Welding Machine
Welding Material :
Carbon Steel Stainless Steel Aluminum
Brand Name :
Xingweihan
Machine type :
Machine Seam Welding
condition :
New
Welding Mode :
High-Frequency Seam Welding
MOQ :
1 set
After-sales Service Provided :
Free spare parts, Field installation, commissioning and training
voltage :
220 V, 480 V, 380V/50Hz
warranty :
1 Year
welding diameter :
Custonized
Price :
$28,000-30,000 / set
usage :
Seam Welding Machine Cnc For Shock Absorber
Place of Origin :
Sichuan, China
Thickness :
2+2MM
Function :
Machine Weld Seam
Certification :
CE, RoHS, ISO
Keyword :
Side Seam Welding Machine
dimensions :
2400*3000*2600mm(94.49*118.11*102.36in)
weight (kg) :
2600
Application :
Seam Resistance Welder
After Warranty Service :
Video technical support, Online support and Spare parts
power (kw) :
80-160
Description
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
ChengDu Xinweihan is one of the leading welding equipment manufacturer in china, Specialized in manufacturing and provide customers with a complete set of welding solutions. A R&D team of more than 20 engineers., and a 20000 sq.m manufacturer, which guarantees that we can offer customers the most professional welding advice and after-sales service. And we have our own overseas technical service teams in many countries in Southeast Asia and South America to provide customers with on-site installation and maintenance services.(Please contact us to ask if there is a technical team in your country)
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders

Product Description

Horizontal Type Hot Selling Product 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders for Steel
The horizontal automatic seam welding machine is mainly composed of a host frame, pneumatic transmission mechanism, human-computer interaction interface, silver tile conductive components, transplanting mechanism, differential transmission mechanism, secondary circuit, welding transformer, welding controller, water and gas circuit system and other components. Specially designed for welding shock absorbers, shock absorbers, and piston cylinders, and suitable for workpieces of different specifications, with high cost-effectiveness. Automatic feeding and welding to improve production efficiency.
Technical Parameters
Model/Item
Unit
FN-80-H
FN-100-H
FN-160-H
FN-100-E
FN-160-E
Rated power
KVA
80
100
160
100
160
Voltage input
V
380
380
380
380
380
Frequency
Hz
50
50
50
50
50
Max. short circuit current
KA
26
30
40
30
40
Working stroke
mm
100
100
100
100
100
Welding efficiency
m/min
0.7-3.9
0.7-3.9
0.7-3.9
0.7-3.9
0.7-3.9
Max. force
N
6000
6000
7800
6000
7800
Max. welding capacity
mm
1.2+1.2
1.5+1.5
2.0+2.0
1.5+1.5
2.0+2.0
Motor Power
W
550
750
750
750
400
Cooling consumption
L/min
8
8
10
8
10
Weight
Kg
380
510
630
530
700

Main Features

1. Driving method: Horizontal seam welding machines are usually driven by servo motors, which have the characteristics of small torque fluctuations and stable speed. The rotation of the workpiece is driven by the motor to rotate the electrode, which is driven by the frictional force between the electrode and the workpiece. The motion is smooth and the speed is adjustable.
2. Control system: Industrial PLC is used to control the operation of the whole machine. The process can be compiled and set, with a short operating cycle, fast response speed, accuracy, stability, and reliability. Through touch screen for human-machine interaction, it is convenient to set various welding process parameters; Set and modify device parameters and perform various manual and automatic actions; View real-time welding parameters and quantities, which can be uploaded through the MAS system or downloaded from a USB drive.
3. Automation level: The equipment can match different welding fixtures according to the workpiece situation, and can achieve semi-automatic welding mode of manual feeding and automatic welding; It can also be a fully automatic welding method with automatic feeding and welding by the equipment; It can also be connected to the production line to achieve automatic welding on the production line.
General Strctures
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Detail Images
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders

Customized Fixtures and Moving Components

Adopting a cyclic transplanting mechanism can achieve fully automatic welding and improve welding efficiency.The device has high compatibility and can weld workpieces of different diameters and lengths.
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders

Cylinder

Adopting aluminum alloy cylinder barrel, low damping sealing ring, and light friction ring combination with hydraulic cylinder, the surface is wear-resistant and has a long service life, achieving extremely high dot speed, electrode pressurization, smooth and fast.
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders

Gas Storage Tanks

The projection and spot welding machine is equipped with a dedicated gas storage tank, which is beneficial for reducing welding pressure fluctuations and ensuring stable welding force.
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders

Waterway Components

All waterway components undergo surface treatment to prevent rusting, and waterway drainage is independently discharged to the water tank. Based on the outflow situation, blockages in the waterway can be observed and eliminated.
Scene images
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
More details, please contact!
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Multi Types Of Seam Welders
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Similar Product
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Projection Welding Machine For Shock Absorber
The shock absorber storage cylinder convex ring special machine is a specialized equipment developed for the forming process of automotive shock absorber storage cylinder convex rings. It adopts advanced hydraulic forming and precision control technology to achieve high-precision and high-efficiency processing of the storage cylinder convex ring parts. This device is designed specifically for the manufacturing of core components of automotive suspension systems, and can meet the requirements of convex ring forming for different specifications of oil storage cylinders.
Horizontal Type 160Kva Mfdc Automatic Welding Machine Piston Bore Shock Absorber Seam Welders
Shock Absorber Welding Machine
Designed based on the workpiece with protrusions on the bracket and inner plate provided by the customer. The thickest plate thickness of the welding material is 4.5mm+2.5mm (with 5 welding protrusions on one side). This welding machine adopts pneumatic pressurization and vertical movement of the upper electrode. Each model has the characteristics of simple and compact structure, novel and beautiful appearance, stable performance, safe and reliable use, high efficiency and energy conservation.
