220lm/W IP68 Waterproof LED Street Light Module High Lamp Luminous Efficiency
220lm/W IP68 Waterproof LED Street Light Module High Lamp Luminous Efficiency
220lm/W IP68 Waterproof LED Street Light Module High Lamp Luminous Efficiency
220lm/W IP68 Waterproof LED Street Light Module High Lamp Luminous Efficiency
220lm/W IP68 Waterproof LED Street Light Module High Lamp Luminous Efficiency
220lm/W IP68 Waterproof LED Street Light Module High Lamp Luminous Efficiency
Specifications
Brand Name :
Vbrite
Model Number :
VB-M09
Place of Origin :
China
MOQ :
10PCS
Packaging Details :
Carton Packing
Delivery Time :
10~15Day
Payment Terms :
L/C,T/T,D/A,D/P,Western Union
Name :
LED Street Light Module
Power :
40W
LED Chip :
SMD5050
CCT :
3000K~5700K
CRI :
>70/>80/>90
Beam Type :
20°/ 40°/ 60°/90°/150×70°
Lens Dimension :
250x75mm
Product Dimension :
300x75x50mm
Description

High Lamp Luminous Efficiency 220lm/W LED Module Ip68 Waterproof Street Light Module

Product Description

The module adopts a flexible design with a variety of angles to choose . Easy installation, greatly saving construction time. It has a high color rendering index (CRI>90), soft and comfortable light, and effectively protects eyesight. The outdoor model is IP67 waterproof and dustproof, fearless of wind and rain, suitable for advertising light boxes, building outline lighting and other scenarios; whether it is home audio-visual entertainment, store atmosphere creation, or large-scale project lighting, this LED module can provide efficient, energy-saving, and intelligent lighting solutions.

Specification

Model VB-M09-40
Power 40W
Driving Current 0.84A
Voltage DC42-48V
LED chip SMD 5050
CCT 4000K / 5000K / 5700K
CRI > 70 ( >80, >90 optional )
Efficacy 205lm/w
Lumen Flux 8200lm
Beam Type 20° / 40° / 60° / 90° /150x70°
Lens Dimension 250x75mm
IP Rating IP66
Working Temp.(°C) -40℃ ~50℃, 20%~90% RH
Storage Temp.(°C) -40℃ ~50℃, 10~90% RH
Lifetime >50,000 hours
Main Material Aluminum6063 + Optical PC
Product Dimension 300x75x50mm
Carton 425x350x455mm, 40pcs/CTN
N.W.(KG) 0.52KG/PCS
G.W.(KG) 25.5KG/CNT

Features

  1. High-grade LED chips ensure bright and uniform light output.
  2. Suitable for commercial and industrial lighting
  3. energy-saving and environmentally friendly, power consumption is as low as 1/10 of traditional light sources
  4. Lifespan 50,000 hours, and replacement frequency is reduced.
