SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool
SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool
SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool
SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool
SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool
SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool
SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool
SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool
SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool
SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool
Specifications
Brand Name :
QFMH
Model Number :
SK30,SK40,SK50
Place of Origin :
CHINA
MOQ :
10PCS
Price :
USD 10/PC
Payment Terms :
L/C, D/P, T/T, Western Union
Supply Ability :
10000PCS MONTH
Delivery Time :
5 DAYS
Packaging Details :
CARTON
AppliCATEion :
CNC clamping Machining
Coating :
TiN
Flute Type :
Single Flute
Material :
20CrMnTi
Product Name :
SK50 Tool Holder
Shank Type :
sk
Tolerance :
H6
Type :
DIN69872 Tool Holder
Size :
sk50 oz25
Brand :
SK
Description

SK50 OZ Collet Chuck,applicable to the main shaft of the SK3O and is also suitable for similar woodworking machinery and equipment, such as industry, such as the long, peace, shoda brands such as CNC machine tool equipment, the handle the special configuration of a screwdriver handle, knife beam configuration model for 0Z25.SK OZ Collet chuck DIN6388 OZ collet clamping straight shank tools of various sizes ,straight shank collet clamping tool for various sizes of cylindrical shank, high speed and high precision machining.Mechanical spindle and cutting tools and other accessories.High Precision SK shank Tool Holder ,balanced G6.3 or G2.5 For choose.

SK OZ Collet Chuck SpecifiCATEEions
1,SK OZ Collet Chuck Material: 40Cr, 20CrMnTi
2, SK OZ Collet Chuck Accuracy: 0.005mm
3, SK OZ Collet Chuck Taper tolerance: AT3
4, SK OZ Collet Chuck Hardness: 52-58HRC
5, Coolant: AD, B, AD/B can be made according to cutomer requirements
6, ball bearing Nut
7, Dynamic balancing: G6.3/12000rpm, G2.5/25000rpm

SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool

SK40 OZ25 Collet Chuck 100mm High Precision Tool Holder cnc machine tool

MODEL L D COLLET TYPE
SK40-OZ25-100 100 60 OZ25
SK40-OZ32-90 90 72 OZ32
SK50-OZ25-85 85 60 OZ25
SK50-OZ25-100 100 60 OZ25
SK50-OZ32-70 70 72 OZ32
