320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
Specifications
Table Travel (X) (mm) :
700/680
Machining Capacity :
Light Duty
Table Travel (Y) (mm) :
255/240
Table Travel (Z) (mm) :
350/330
Spindle Taper :
7:24 ISO50
Range of Spindle Speed(r.p.m) :
30 - 1500 r.p.m
Place of Origin :
Henan, China
Brand Name :
TIMEWAY
Model Number :
VM320W
Type :
VERTICAL
Spindle Motor Power(kW) :
7.5
Dimension(L*W*H) :
2294*1780*2150mm
Weight (KG) :
2860
Warranty :
1 Year
Key Selling Points :
Competitive Price
Marketing Type :
New Product 2024
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Name :
Vertical Knee-type Milling Machine
Machine Type :
Veritcal
After-sales Service Provided :
Provided
Function :
Machining Metal
Table size :
320x1325mm
T-slot (No./width/pitch) :
3/18/90mm
Distance from spindle nose to table :
60-410mm
Spindle bore diameter :
29mm
Machine weight :
2860kg
Number of Axes :
3
Condition :
New
Applicable Industries :
Building Material Shops, Machinery Repair Shops, Construction works , Energy & Mining
Showroom Location :
Morocco, Kenya, South Korea, Sri Lanka, Kazakhstan, Uzbekistan, Tajikistan, Malaysia, Australia, United Kingdom, Italy, Germany, Viet Nam, Indonesia, Mexico, Spain
Core Components :
Bearing, Motor
Year :
2024
Price :
$12,600.00/sets 1-2 sets
MOQ :
1 set
Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
Product Description
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication

STANDARD ACCESSORIES:

Draw bar
Coolant system
Chip tray
Work lamp
Lubrication system
Tools and Tool box
Operator manual

OPTIONAL ACCESSORIES:

2/3-axis digital readout
58pcs clamping kit
Machine vise
Spindle protection guard
Table protection guard
Dividing head
Rotary table
Reducing sleeve
Specification
SPECIFICATION
UNIT
VM320W
Table size
mm
320x1325
T-slot (No./width/pitch)
mm
3/18/90
Distance from spindle nose to table
mm
60-410
Longitudinal travel(manual/auto)
mm
700/680
Cross travel(manual/auto)
mm
255/240
Vertical travel(manual/auto)
mm
350/330
Mill head swivel angle
°
±45°
Spindle bore diameter
mm
29
Spindle taper
-
7:24 ISO50
Spindle speed range
r/min
30-1500
Spindle speed step
steps
18
Table longitudinal feed speed (X)
mm/min
23.5-1180
Table cross feed speed (Y)
mm/min
15-786
Table vertical feed speed (Z)
mm/min
8-394
Feed speed steps (X/Y/Z)
steps
18
Rapid feed speed(X/Y/Z)
mm/min
2300/1540/770
Main motor power
kw
7.5
Feed motor power
kw
1.5
Machine dimensions (Lx WxH)
mm
2294x1780x2150
Machine weight
kg
2860
Client feedback
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
Factory Display：
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
320x1325mm Table Size Vertical Knee-type Milling Machine VM320W for Metal Fabrication
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
