2550KG Weight / 360 x 1250mm Table Size / Universal Swivel Head Knee Type Milling Machine / US360B
2550KG Weight / 360 x 1250mm Table Size / Universal Swivel Head Knee Type Milling Machine / US360B
Specifications
Table Travel (X) (mm) :
1000
Machining Capacity :
Heavy Duty
Table Travel (Y) (mm) :
320
Table Travel (Z) (mm) :
400
Spindle Taper :
ISO40
Range of Spindle Speed(r.p.m) :
35 - 1600 r.p.m
Place of Origin :
China
Brand Name :
TIMAC, TIMEWAY
Model Number :
US360B
Type :
Universal
Spindle Motor Power(kW) :
3
Voltage :
220/380V
Dimension(L*W*H) :
2220x1660x2020mm
Weight (KG) :
2550
Warranty :
1 Year
Key Selling Points :
Competitive Price
Marketing Type :
Ordinary Product
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
CNC or Not :
Normal
Milling Machine :
Universal Swivel Head Knee Type Milling Machine
Table size :
1250x360mm
Diameter of spindle quill :
100mm
Spindle rotate speeds :
35-1600rpm
Table travel (Horizontal) :
1000mm
Table travel (Cross) :
320mm
Table travel (Vertical) :
400mm
N.W./G.W. :
2350/2550kg
Number of Axes :
2
Condition :
New
Applicable Industries :
Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Construction works , Energy & Mining
Showroom Location :
Argentina, Romania, Australia, Brazil, Pakistan, Russia, Spain
Core Components :
Bearing, Motor, Pump, Gear
Table Travel (mm) :
1000/320/400mm
Packaging Details :
Wood case(can be fumigated)
Port :
China Port
Supply Ability :
65 Set/Sets per Month
Price :
$10,000.00/sets 1-2 sets
MOQ :
1 set
Description

360 x 1250mm Table Size / Universal Swivel Head Knee Type Milling Machine / US360B

2550KG Weight / 360 x 1250mm Table Size / Universal Swivel Head Knee Type Milling Machine / US360B

Features:

1. Both horizontal and vertical spindles, with vertical milling head can swivel ±360, realizing multiple

surface processing with workpiece static;

2. Full gear type horizontal spindle box, ISO40 spindles, vertical and horizontal milling can exchange

without rotating the ram;

3. Table surface and guideways are hardened and ground;

4. Automatic feeds on X, Y axes, motorized elevating of table on Z axis;

5. Extended length and thickness saddle, more rigid and stable.

Parameter:

Specification

US360B

Spindle taper

ISO40(V), ISO40(H)

Diameter of spindle quill

100mm

Distance from vertical spindle nose to table

200-600mm

Distance from horizontal spindle centerline to table

0-400mm

Distance from vertical spindle centerline to column

300-900mm

Spindle rotate speeds

(11step)35-1600rpm(V),(12steps)40-1300rpm(H)

Distance from horizontal spindle centerline to ram

350mm

Vertical milling head swivel angle

±360°

Table size

1250×360mm

T-slot Number/width/distance

3/18mm/80mm

Table loading capacity

400kg

Table travel(Horizontal/Cross/Vertical)

1000/320/400mm

X, Y-axes feed speed

22-555mm

X, Y-axes rapid feed speed

1080mm/min

Z-axis rapid feed speed

590mm/min

Column guideway type

Rectangular type

Cross guideway type

Rectangular type

Longitudinal guideway type

Dovetail type

Main motor

3kw(V), 3kw(H)

X, Y axes feed diving motor

750w

Z-axis rapid feed motor power

1100w

Coolant pump power

90w(25L)

Overall dimension(LxWxH)

2220x1660x2020mm

Packing size(LxWxH)

1800x1900x2250mm

N.W./G.W.

2350/2550kg
