Specifications
Table Travel (X) (mm) :
350
Machining Capacity :
Light Duty
Table Travel (Y) (mm) :
200
Table Travel (Z) (mm) :
350
Spindle Taper :
MT4
Range of Spindle Speed(r.p.m) :
30 - 2050 r.p.m
Place of Origin :
China
Brand Name :
TIMAC TIMEWAY
Model Number :
UTM260K
Type :
Universal
Spindle Motor Power(kW) :
3
Voltage :
380V
Dimension(L*W*H) :
1450x1445x1650
Weight (KG) :
1200
Warranty :
1 Year
Key Selling Points :
Easy to Operate Drilling Milling Machine
Marketing Type :
Ordinary Product
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
Horizontal worktable size :
280x700
Vertical worktable size :
260x750
Longitudinal travel (X) :
350
Ram cross travel (Y) :
200
Vertical travel (Z) :
350
Vertical mill spindle quill travel :
80
Vertical spindle swivel angle :
±45°
Vertical spindle taper :
MT4
Vertical spindle speed :
150-1660 (8)
Horizontal spindle taper :
MT4
Number of Axes :
3
Condition :
New
Applicable Industries :
Machinery Repair Shops, Manufacturing Plant
Showroom Location :
Sri Lanka, Romania, Nigeria, Egypt, United States, Philippines
Core Components :
Bearing, Motor, Pump, Gear, PLC, Pressure vessel, Gearbox
Table Travel (mm) :
280x700
Packaging Details :
Wooden cases(can be fumigated)
Port :
China Port
Supply Ability :
150 Set/Sets per Month
Price :
$26,000.00/sets 1-2 sets
MOQ :
1 set
Description
One-Stop Shopping
You can click on the picture to view the products you are interested in
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Products Description
Tool Milling Machine

Features:

---Hand wheel guarantees simple and precise feed settings.
---Complete with manual, automatic and rapid feed in all three axis.
---Central lubrication in guideways comes standard.
---Clear design of speed and feed controls.
---Vertical clamping area with 5 T-slots allows clamping of work table, universal tilting table and oversize workpieces.
---Optimal adjustments of spindle speed and feed allow for economic machining of various materials.
---Solid grey cast-iron machine base guarantees precision and minimizes vibrations.
---Ultimate machine for tool and mould construction, training, industry, model making and prototyping etc.
---Hardened and polished guideways guarantee top accuracy.
---Tiltable vertical milling head with spindle adjustment and three automatic drill feeds.
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Specifications
Unit
UTM400K
Horizontal worktable size
mm
400x800
Vertical worktable size
mm
250x950
Longitudinal travel (X)
mm
500
Ram cross travel (Y)
mm
350
Vertical travel (Z)
mm
400
Loading capacity
kg
300
Main motor power
kw
3
Machine dimensions (LxWxH)
mm
1820×1640×1710
Packing size (LxWxH)
mm
2050x1760×2080
STANDARD ACCESSORIES:
OPTIONAL ACCESSORIES:
Ÿ Draw bar
Ÿ Coolant system
Ÿ Chip tray
Ÿ Work lamp
Ÿ Lubrication system
Ÿ Tools and Tool box
Ÿ Operator manual

Ÿ 2/3-axis digital readout
Ÿ 58pcs clamping kit
Ÿ Machine vise
Ÿ Spindle protection guard
Ÿ Table protection guard
Ÿ Dividing head
Ÿ Rotary table
Ÿ Reducing sleeve
Client feedback
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Our Services
1. Free replacing parts available in the warranty period. Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine. 3. Overseas after service center available in some region. 4. Engineer overseas service available on the requirement of customer(relative cost born by customer).
Company Introduction
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Factory Display：
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Factory Profile：
Our factory was established in 2014. It has professional technicians, a research and development team, manufactures and sells CNC equipment and provides professional customized services.Our products are widely used in mold processing, 3C products, agricultural machinery, petroleum machinery, auto parts processing, aerospace industry, etc., selling more than 60 countries and regions in domestic and abroad.
Text Introduction：
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Company Profile：
Timeway Machine Tool Co., Ltd. is a professional machine tool manufacturing enterprises, the main products include lathe, milling machine, grinding machine, etc., and according to customer needs we also can design and manufacture various special purpose machines, to provide relative technology upgrading and transformation services in machine tool field.
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Customer Visited：
So far, we have received many customers from abroad, and they are all very satisfied with our company and products
Versatile Vertical and Horizontal Tool Turret Milling Machine with High Spindle Speed
Exhibitions：
Since the establishment of the Ministry of Foreign Trade, we have participated in various domestic and international exhibitions such as the Autumn Canton Fair, Beijing Exhibition, Shanghai Exhibition, Moscow, Ethiopia, and Russia, and have maintained long-term friendly cooperative relations with exhibition customers.
FAQ
Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price; 2 . Professional R&D team and 25 years export experience; 3 . Exported more than 60 countries; 4 . CE, ISO Certificates; 5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager); 6 . 12 months quality warranty; 7 . Oversea engineers available for problem resolving; Q: Do you have QC or any safety standards for your machinery? A: yes, we have established a highly strict quality control department to guanrantee good quality. Q: What's the MOQ? A: 1 set (Only some low cost machines will be more than 1 set ) Q: What about the payment terms? A: (1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment; (2) Irrevocable LC at sight; (3) Western Union, MoneyGram, etc. Q: How about the warranty? A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
