VM360A Vertical Knee-type Milling Machine with Range of Spindle Speed 60 1700 r.p.m
VM360A Vertical Knee-type Milling Machine with Range of Spindle Speed 60 1700 r.p.m
VM360A Vertical Knee-type Milling Machine with Range of Spindle Speed 60 1700 r.p.m
VM360A Vertical Knee-type Milling Machine with Range of Spindle Speed 60 1700 r.p.m
Specifications
Table Travel (X) (mm) :
600
Machining Capacity :
Medium Duty
Table Travel (Y) (mm) :
320
Table Travel (Z) (mm) :
450
Spindle Taper :
ISO50
Range of Spindle Speed(r.p.m) :
60 - 1700 r.p.m
Place of Origin :
Henan, China
Brand Name :
TIMAC
Model Number :
VM360A
Type :
VERTICAL
Spindle Motor Power(kW) :
4
Voltage :
As request
Dimension(L*W*H) :
1900x1850x1800mm
Weight (KG) :
2100
Warranty :
one year, 1year
Key Selling Points :
High-accuracy
Marketing Type :
Ordinary Product
Machinery Test Report :
Provided
Video outgoing-inspection :
Provided
Warranty of core components :
1 Year
After-sales Service Provided :
Engineers available to service machinery overseas
CNC or Not :
Normal
Vertical Knee-type Milling Machine :
Vertical Knee-type Milling Machine
Certification :
CE, ISO
Power :
4kw
Weight :
2100,2200kg
X axis Working table stroke :
600mm
Y axis Working table stroke :
320mm
Z axis Working table stroke :
450mm
Number of Axes :
3
Condition :
New
Applicable Industries :
Garment Shops, Building Material Shops, Manufacturing Plant
Showroom Location :
Malaysia, Turkey, Brazil, Indonesia
Core Components :
Other
Table Travel (mm) :
600X320x450
Year :
2022
Packaging Details :
In plywood cases.
Port :
China port.
Supply Ability :
300 Set/Sets per Month
Price :
$5,450.00/sets >=1 sets
MOQ :
1 set
Description

Vertical Knee-type Milling Machine VM360A

VM360A Vertical Knee-type Milling Machine with Range of Spindle Speed 60 1700 r.p.m

Model Unit VM360A
Spindle taper ISO50
Distance from spindle nose to table mm 60-540
Spindle speed r.p.m (12steps)60-1700
Table size mm 1250×360
Table travel(longitudinal/cross/vertical) mm 600×320×450
X,Y axes feed speed mm/min 22-555(8steps)
X,Y axes rapid feed speed mm/min 1080
Z axis rapid elevate speed mm/min 590
Max.weight of workpiece kg 400
T slot(No./width/distance) mm 3/18/80
Main motor kw 4
X,Y axes auto-feed drive motor w 750
Z axis motor power w 1100
Coolant pump power w 90
Overall dimension(L×W×H) mm 1900×1850×1800
N.W./G.W. kg 2100/2200

Features:

1. Hardened and ground table surface;

2. Automatic feeds on X,Y axes, motorized rise and fall of table on Z axes;

3. Rectangular column guide way with high stability.

Why Choose Us
Why choose TIMEWAY MACHINE?

1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 70 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving.
