D28 Welding Table for Robotic Welding Automation Systems
D28 Welding Table for Robotic Welding Automation Systems
D28 Welding Table for Robotic Welding Automation Systems
D28 Welding Table for Robotic Welding Automation Systems
D28 Welding Table for Robotic Welding Automation Systems
D28 Welding Table for Robotic Welding Automation Systems
D28 Welding Table for Robotic Welding Automation Systems
D28 Welding Table for Robotic Welding Automation Systems
Specifications
Supply Ability :
500 units/month
Table Flatness :
±0.1 mm /1000 mm
Model Number :
D28
Material Option :
Q355 steel plate/HT300 cast iron
MOQ :
1 PCS
Delivery Time :
15-25 work days
Nitriding Layer Depth :
0.15‑0.3 mm
Payment Terms :
L/C,D/A,D/P,T/T
Hole‑Pitch Accuracy :
100 mm ±0.05 mm
Side Panel Height :
200 mm
Price :
500-1500 USD
Perpendicularity of Adjacent Faces :
±0.1 mm /200 mm
Table Thickness :
25mm
Working Temperature :
‑10℃ ~ +60℃
Certification :
CE
Place of Origin :
WUXI , CHINA
Packaging Details :
4000*2000*200mm
Brand Name :
WUXI LEMAR
Nitriding Hardness :
HV550+
Description
D28 Welding Table for Robotic Welding Automation Systems

The D28 Welding Table for Robotic Welding Automation Systems serves as the high-reliability mechanical reference core inside modern robot welding cells. Following international D28 modular hole-grid specification, this 3-dimensional welding fixture platform is specially optimized to counteract robotic dynamic vibration and cyclic welding heat load.


Fully stress-relieved base material paired with plasma nitrided surface preserves critical flatness and hole-position accuracy over years of non-stop automated runs. It supports quick fixture re-tooling, seamless hand-eye vision calibration, offline programming simulation, and easy integration with positioners and robot 7th axis rails.

D28 Welding Table for Robotic Welding Automation Systems D28 Welding Table for Robotic Welding Automation Systems

Whether you build single robot islands or large-scale multi-station welding lines, this D28 worktable eliminates positioning drift and safeguards your robot welding program consistency for heavy structural workpieces.

Key Precision Parameters
Item Standard Parameters for D28 Robotic Welding Table
Table Flatness ±0.1 mm /1000 mm
Hole-Pitch Accuracy 100 mm ±0.05 mm
Perpendicularity of Adjacent Faces ±0.1 mm /200 mm
Static Load Capacity 700 kg per support leg; total static load 3-5.6 tons; dynamic load (under robot vibration condition) ≥2 tons
Table Thickness 22-25 mm; side height 200 mm, reinforced bottom ribs to suppress deformation
Mainstream Size Specifications

Standard dimensions (Length × Width in mm):

1000×800, 1200×1000, 1500×1500, 2000×1000, 2400×1200, 3000×1500, 4000×2000

- Small-to-medium robot cells: 1500×1500 / 2000×1000

- Construction machinery / vehicle frame robotic lines: 2400×1200, 3000×1500, 4000×2000 (large table surfaces; multiple units can be joined to expand the working area)

Leg options: Fixed heavy-duty legs (preferred for robotic production lines), height-adjustable legs, and casters with brakes (for commissioning stations). Fixed heavy-duty legs are prioritized for robotic automation lines to eliminate vibration or displacement during operation.

Product Advantages
D28 Welding Table for Robotic Welding Automation Systems
  • Stable precision with stress-relief treatment, no positioning drift for long-run operation of the D28 welding table for robotic welding automation systems
  • ISO D28 100 mm hole grid, 5-sided machining, full compatibility with global standard accessories for this 3D modular welding table
  • Thick tabletop & reinforced rib structure, high load capacity, anti-resonance against robot dynamic vibration inside the robotic welding cell
  • Plasma nitrided nitrided D28 welding table, HV450-630 hardness, anti-spatter & anti-arc-burn for easy maintenance
  • Seamless integration with positioners, robot seventh-axis and zero-point clamping units for stress-relieved D28 worktable
  • HT300 cast iron / Q355 steel optional for different automated production scenarios
  • Laser-tracker measured test reports provided for project acceptance
  • Custom dimensions and multi-table splicing for large robotic welding lines
FAQ
Q: Can it integrate with robot seventh axis and positioners?
A: Yes. This stress-relieved D28 worktable works with 7th-axis rails, positioners and zero-point clamping. Table and 7th-axis shall share the same concrete foundation to prevent coordinate shift.
Q: What foundation is needed for installation?
A: C30 concrete foundation ≥200 mm thickness with anchor bolts. Do not place on pure epoxy floor. Recheck flatness after thermal welding test.
Q: Can multiple 3D modular welding tables be spliced together?
A: Yes. Use D28 locating pins for splicing. All tables must sit on one shared rigid foundation to avoid misalignment.
Q: What test reports can you provide?
A: Laser-tracker inspection reports for flatness, hole-pitch and perpendicularity. Nitriding hardness report is available upon request.
Q: Can you offer CAD files for offline programming?
A: Yes, STEP / IGES files are provided for workstation layout and robot OLP simulation.

Ready to source your D28 Welding Table for Robotic Welding Automation Systems?

Share your robotic welding project parameters with us. We provide custom sizes, inspection reports and complete supporting accessories.

Submit your inquiry and get a prompt reply from our technical-sales team.

Send your message to this supplier
