D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
Specifications
Brand Name :
WUXI LEMAR
Model Number :
D28
Certification :
CE
Place of Origin :
WUXI
MOQ :
1
Price :
500-1500 USD
Payment Terms :
L/C,D/A,D/P,T/T,Western Union
Supply Ability :
500 units/month
Delivery Time :
15-25 work days
Packaging Details :
3000*2000*200mm
System Hole Diameter :
φ28mm
Standard Grid Spacing :
100×100mm
Positioning Accuracy :
±0.05mm
Table Flatness :
≤0.3mm / 1000mm
Table Material :
Q355 Steel/ HT300 Cast iron
Average Load Capacity :
6-8 Tons / ㎡
Working Sides :
5-sided usable (top + four side faces)
Table Leg Standard Height :
620mm
Leg Option :
Fixed / Height Adjustable / With Universal Casters
Description
D28 3D Precision Welding Table Fixture System - Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
Workbench Features
  • Tabletop: The D28 3D welding table has millimeter scale lines and coordinate marks on all five sides (top and four sides) for quick alignment
  • Strengthening Ribs: Densely covered intersecting ribs at the bottom to prevent deformation and enhance rigidity
  • Leg/Frame Options: Fixed, telescopic, hydraulic lifting, or mobile with casters
Modular Fixture System
  • Positioning Type: L-shaped angle iron, U-shaped square box, V-shaped block, positioning pin, right angle block, angle gauge
  • Clamping Type: Quick clamp (vertical/horizontal/45°), spiral clamp, telescopic clamp
  • Locking Type: D28 quick locking pin (self-centering with five steel balls, clamping force ~5t, shear force ~25t), countersunk pin, connecting bolt

D28 3D Precision Welding Table Fixture System Multiple Sizes AvailableD28 3D Precision Welding Table Fixture System Multiple Sizes Available
Production Specifications
Item No. Specification (LxW) mm Height (mm) Material
1 4000x2000 200/150 Q355/HT300 Cast iron/Stainless steel
2 3000x2000 200/150 Q355/HT300 Cast iron/Stainless steel
3 3000x1500 200/150 Q355/HT300 Cast iron/Stainless steel
4 2500x2000 200/150 Q355/HT300 Cast iron/Stainless steel
5 2500x1500 200/150 Q355/HT300 Cast iron/Stainless steel
6 2000x2000 200/150 Q355/HT300 Cast iron/Stainless steel
7 2400x1200 200/150 Q355/HT300 Cast iron/Stainless steel
8 2000x1500 200/150 Q355/HT300 Cast iron/Stainless steel
9 1500x1500 200/150 Q355/HT300 Cast iron/Stainless steel
10 2000x1000 200/150 Q355/HT300 Cast iron/Stainless steel
11 1200x1200 200/150 Q355/HT300 Cast iron/Stainless steel
12 1200x1000 200/150 Q355/HT300 Cast iron/Stainless steel
13 1000x1000 200/150 Q355/HT300 Cast iron/Stainless steel
14 1000x800 200/150 Q355/HT300 Cast iron/Stainless steel
Core Advantages
  • 3D Flexibility: Five-sided positioning allows clamping from any angle, accommodating horizontal, vertical, and multi-angle welding for complex frames, housings, and racks
  • High Precision and Consistency: Mesh hole system and precision machining ensure high repeatability and positioning accuracy, resulting in strong consistency in mass production and reduced rework
  • High Efficiency and Time Saving: Modular design allows workpiece clamping within 10 minutes, eliminating custom-made tooling and significantly shortening changeover cycles
  • Durable and Economical: Nitrided/quenched surfaces are anti-spatter and wear-resistant for long service life; fixtures can be recombined and reused for low long-term costs
  • Safe and Stable: Strong rigidity and reliable clamping ensure no workpiece displacement or vibration during welding, guaranteeing weld quality and operational safety
Fixture Accessories
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
D28 3D Precision Welding Table Fixture System Multiple Sizes Available
Key Points for Purchasing
  • Size Selection: Based on maximum workpiece size plus reserved operating space
  • Tabletop Material: Heavy duty/high-frequency use with optional quenching and nitriding; lightweight ordinary carbon steel
  • Accuracy level: For high-precision requirements (robot welding), choose D28 Welding table with flatness ≤ 0.2mm/1000mm
  • Fixture Configuration: Basic set includes angle iron, square box, quick locking pin, and clamp; complex workpieces require angle blocks, extension parts and fine adjustment components
  • Leg Types: Fixed (stable), lifting (suitable for different workstations), mobile (multi-workstation circulation)
Frequently Asked Questions
Q: What is your warranty period?
A: 1 year warranty for the welding table body; lifelong technical support.
Q: How to install and use the table?
A: We provide installation manual, assembly drawing and operation guide for free.
Q: Can you customize logo and package?
A: Yes, OEM & ODM service is available, including custom logo and wooden export package.
Q: Do you have CE certificate?
A: Yes, we have CE certification, meeting European market standards.
Q: What is your production quality standard?
A: Strict raw material inspection, full CNC machining, stress relief treatment, whole table flatness tested one by one before delivery.
We supply premium D28 3D Precision Welding Table Fixture System with multiple sizes available.
Feel free to contact us to get full specifications and quotations.
