Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
Specifications
Supply Ability :
500 units/month
Splicing Method :
Flexible Unlimited Modular Splicing
Model Number :
D28
Matching Hole System :
System 28（φ28.15±0.03mm）
MOQ :
1 PCS
Delivery Time :
15-25 work days
Leg Support :
2 tons / m²
Payment Terms :
D/A,L/C,D/P,T/T
Hole Position Tolerance :
≤ ± 0.05 mm
Hole Pitch Accuracy :
±0.05mm
Price :
500-1500 USD
Flatness Accuracy :
≤0.5mm/m²
Flatness Tolerance :
≤0.1mm per square meter
Hole Specifications :
28mm + 100mm grid
Certification :
CE
Place of Origin :
WUXI , CHINA
Packaging Details :
4000*2000*200mm
Brand Name :
WUXI LEMAR
Tensile Strength :
≥300MPa
Description
Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding

If you are searching for a reliable platform for oversized metal fabrication, our Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding is your optimal choice.

This modular splicable D28 3D welding table supports free extension of working dimensions via panel splicing, comes with accurate D28 100mm hole pitch for full 3D multi-direction clamping, and offers strong load capacity and anti-spatter nitrided surface. It perfectly matches the welding demands of aluminum yacht frames, heavy truck frames and various extra large metal structural parts.

Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
D28 3D Welding Table Specification Chart
Item Specification
Standard Table Sizes (Single Panel) 1000×1000mm / 1500×1000mm / 2000×1000mm / 3000×1500mm
Splicing Capability Unlimited length & width extension, customizable 2m-20m ultra-large platform
Hole System Standard D28 (Φ28mm standard hole)
Hole Spacing 100mm × 100mm grid, tolerance ±0.05mm
Clamping Structure 5-sided full perforation (top + four vertical sides), 3D omnidirectional clamping
Tabletop Thickness 25mm standard / 30mm / 35mm reinforced optional
Material Option HT300 Stress-relieved Cast Iron / Q355 High-strength Steel
Surface Treatment Overall gas nitriding hardening, HV380-450 hardness, anti-spatter & anti-rust
Flatness Accuracy ≤0.3mm / 1000mm
Verticality Tolerance ≤0.1mm / 200mm
Single Panel Load Capacity 10 tons uniform load
Support System Fixed legs / Movable brake casters with ±20mm height adjustment
Compatible Fixtures Full universal D28 standard fixture system
Application Extra-large metal structures, aluminum boat frames, truck chassis, mechanical frames
Certification CE compliant, full factory inspection report provided
Core Advantages
Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding Flexible Splicing D28 3D Welding Table For Extra Large Metal Component Welding
Solves Extra-Long Workpiece Challenges

Standard welding tables have limited lengths, making it impossible to fully position workpieces spanning several meters—such as ship frames, trailer main beams, or large aluminum boat skeletons. By joining multiple D28 welding tables to form a seamless, extra-long reference surface, the entire workpiece can be clamped and welded in a single setup; this eliminates the need for segmented re-alignment and significantly reduces dimensional errors.

Flexible Modularity for High Space Utilization

Tables can be detached for independent use when handling smaller workpieces and combined for larger ones. This eliminates the need for a fixed, custom-built monolithic platform, thereby reducing factory floor space requirements and equipment procurement costs.

Seamlessly Integrated Reference Surfaces

All table plates feature standardized hole patterns, ensuring a continuous grid without misalignment when joined. Fixtures and positioning blocks can be used interchangeably across tables, eliminating the need for custom-made tooling.

Typical Application Scenarios
  • Aluminum Alloy Frames for Ships/Yachts: Assembly and welding of aluminum hulls, keels, and deck frameworks
  • Rail Transit/Construction Machinery: Excavator arms, trailer frames, container skeletons, and tower crane steel structures
  • Heavy Steel Structure Projects: Power transmission towers, large-scale stage trusses, and equipment bases
  • Specialized Vehicles: RV chassis, dump truck main beams, and large agricultural machinery frames
After-Sales Service

We provide long-term after-sales support, including installation guidance, technical training, and lifetime accessory matching. All products enjoy stable quality assurance, helping customers achieve high-efficiency and low-cost long-term production.

Interested in Our Flexible Splicing D28 3D Welding Table?

Submit your information to get in touch with us.

Please note when sending inquiry:

I need a table size: ______ mm × ______ mm,

mainly used for welding ________ (workpiece type).

Enhance your welding efficiency by using our D28 Welding Table!

Contact Amy directly for more details.
