OEM Huawei SFP Optical Transceiver 02312UUG 10GBASE-LR 1000base-Sx
OEM Huawei SFP Optical Transceiver 02312UUG 10GBASE-LR 1000base-Sx
OEM Huawei SFP Optical Transceiver 02312UUG 10GBASE-LR 1000base-Sx
OEM Huawei SFP Optical Transceiver 02312UUG 10GBASE-LR 1000base-Sx
Specifications
Brand Name :
Huawei
Model Number :
02312UUG
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Price :
$25
Payment Terms :
T/T,Western Union,MoneyGram
Supply Ability :
300 pcs
Delivery Time :
3-5 working days
Packaging Details :
White Box
Condition :
Genuine New; In Stock
Interface :
SFP electrical interface
Compatibility :
Huawei switches, routers, and other network devices
Wavelength :
850 nm / 1310 nm / 1550 nm (depending on model)
Dimensions :
13.4 mm x 56.5 mm x 8.5 mm
Weight :
Approx. 30 grams
Datarate :
1.25 Gbps
Productname :
Huawei SFP
Operatingtemperature :
-5°C to 70°C
Standardcompliance :
IEEE 802.3, SFF-8472
Diagnosticmonitoring :
Digital Diagnostic Monitoring (DDM) supported
Hotpluggable :
Yes
Transmissiondistance :
Up to 10 km (model dependent)
Producttype :
Small Form-factor Pluggable (SFP) Transceiver
Powerconsumption :
< 1 W
Connectortype :
LC connector
Description

HUAWEI Original 02312UUG 10GBASE-LR SFP+ Transceiver Module (SMF, 1310nm, 10km, LC, DOM)

HW 02312UUG SFP+ transceiver supports up to 10km link lengths over LC duplex SMF fiber. This transceiver is compliant with SFF-8431, SFF-8432 and IEEE 802.3ae standards. Digital diagnostics monitoring is available via a 2-wire serial interface, as specified in SFF-8472. Featuring low power consumption, high speed, this 10G SFP+ transceiver is ideal for data center, enterprise wiring closet, service provider transport application, Radio & Baseband Unit, etc.

Specifications
Model
02312UUG
Vendor Name
Huawei
Form Factor
SFP+
Max Data Rate
10.3125Gbps
Wavelength
1310nm
Max Cable Distance
10km
Connector
Duplex LC
Media
SMF
Transmitter Type
DFB
Receiver Type
PIN
TX Power
-8.2~0.5dBm
Receiver Sensitivity
<-14.4dBm
Power Budget
6.2dB
Receiver Overload
0.5dBm
Power Consumption
≤1W
Extinction Ratio
>3.5dB
Core Size
9/125µm
Modulation
NRZ
Commercial Temperature Range
0 to 70°C (32 to 158°F)
Protocols
IEEE 802.3ae, SFF-8472, SFF-8431, SFF-8432, SFP+ MSA Compliant, CPRI, eCPRI
