Specifications
Brand Name :
Huawei
Model Number :
S5735I-H8T4S2XN-V2
Certification :
CE
Place of Origin :
China
MOQ :
1pc
Price :
$809
Payment Terms :
T/T,Western Union
Supply Ability :
500 pcs
Delivery Time :
3 working days
Packaging Details :
Huawei Box
Description :
S5735I-H8T4S2XN-V2 (8*10/100/1000BASE-T ports, 4*GE SFP ports,2*10GE SFP+ ports, DIN Rail Mounting, Dual redundant 9.6 to 60V DC supply, Fanless,Without power module)
Condition :
Original New
Description

S5735I-H8T4S2XN-V2 Huawei Industrial Switch 8*10/100/1000BASE-T ports, 4*GE SFP ports,2*10GE SFP+ ports, Dual 9.6 to 60V DC supply


Overview

Table 4-1429 Basic information about the S5735I-H8T4S2XN-V2
Item Details
Description S5735I-H8T4S2XN-V2 (8*10/100/1000BASE-T ports, 4*GE SFP ports,2*10GE SFP+ ports, DIN Rail Mounting, Dual redundant 9.6 to 60V DC supply, Fanless,Without power module)
Part Number 98012185
Model S5735I-H8T4S2XN-V2
First supported version V600R023C00

Components

Figure 4-480 S5735I-H8T4S2XN-V2 appearance

S5735I-H8T4S2XN-V2 Huawei Industrial Switch 8*10/100/1000BASE-T Ports , 4*GE SFP Ports , 2*10GE SFP+ Ports Dual 9.6 To 60V DC Supply


1

Two DC input power sockets

NOTE:

Applicable external power module:

PAC240S56-CN (240 W PoE AC&HVDC Power)

2

One console port

3

One USB port

4

DI port

5

DO port

6

RS485 port

7

Ground screw

NOTE:
It is used with a ground cable.

8

Eight 10/100/1000BASE-T ports

9

Two 10GE SFP+ ports and four 1000BASE-X ports

-

-


Table 4-1430 Ports on the S5735I-H8T4S2XN-V2

Port Connector Type Description Available Components
10/100/1000BASE-T port RJ45 A 10/100/1000BASE-T Ethernet electrical port sends and receives service data at 10/100/1000 Mbit/s.

Ethernet cable
10GE SFP+ optical port SFP+ A 10GE SFP+ Ethernet optical port supports auto-sensing to 1000 Mbit/s. It sends and receives service data at 1000 Mbit/s or 10 Gbit/s.
  • Industrial optical modules
  • 0.5 m and 1.5 m SFP+ dedicated stack cables
  • PEN remote optical modules (V600R024C10 and later versions)
GE SFP optical port SFP

A GE SFP Ethernet optical port supports auto-sensing to 1000 Mbit/s. It sends and receives service data at 1000 Mbit/s.

NOTE:

In V600R023C00, if passing devices are configured to work in HSR mode and there is no north-south traffic, the service indicator is steady on.

Industrial optical modules (only optical modules with 1 Gbit/s transmission speed and transmission distances less than or equal to 10 km are supported)
Console port RJ45 The console port is connected to a console for on-site configuration.

Console cable
USB port USB 2.0 Type A

The USB port can have a USB flash drive connected to upgrade the switch, or transfer configuration files or other files. The USB port can only connect to a USB flash drive that complies with USB 2.0.

USB flash drives from different vendors differ in model compatibility and drivers. If a USB flash drive cannot be used, try to replace it with another one from a mainstream vendor.

USB flash drive
RS-485 port 2x5-Pin Phoenix Connector

The RS-485 port is used for data collection.

  • Standards compliance: RS-485
  • Working mode: Half-duplex
  • Supported rates: 1200 bit/s, 2400 bit/s, 4800 bit/s, 9600 bit/s, 19200 bit/s, 38400 bit/s, 57600 bit/s, and 115200 bit/s
  • Maximum number of nodes that can be mounted: 64
  • Maximum communication distance: 1 km @ 9600 bit/s

The default configurations of the RS-485 port are as follows:

  • Baud rate: 9600 bit/s
  • Flow control: None
  • Parity check: None
  • Stop bits: 1
  • Data bits: 8
NOTE:

During project implementation, if error packets occur on the line, it is recommended that 120 ohms be added between the head end and end of the line.

2x5-Pin Phoenix Connector
DI port 2x5-Pin Phoenix Connector

The DI port is used to check remote communication input and level signals.

Signal type: Passive DI signals, Boolean value (short circuit and open circuit)

2x5-Pin Phoenix Connector
DO port 2x5-Pin Phoenix Connector

The DO port outputs signals so that the connected device can take corresponding actions.

Signal type: Passive DO signals, Boolean value (short circuit and open circuit)

External power supply: voltage less than 60 V DC and circuit current less than 0.5 A

2x5-Pin Phoenix Connector
