Brocade Fiber Switch 7850 Extension Aes256 Encryption 650W Hot Swappable
Brocade Fiber Switch 7850 Extension Aes256 Encryption 650W Hot Swappable
Brocade Fiber Switch 7850 Extension Aes256 Encryption 650W Hot Swappable
Brocade Fiber Switch 7850 Extension Aes256 Encryption 650W Hot Swappable
Specifications
Place of Origin :
CHINA
Compatibility :
Compatible with major SAN storage arrays
Supply Ability :
200pcs
Managementinterface :
Web GUI, CLI, SNMP
Model Number :
7850 Extension Switch
Portcount :
16 to 128 ports
Packaging Details :
Carton packaging
Usecase :
Enterprise SAN, Data Center Storage Networking
Portspeed :
8 Gbps, 16 Gbps, or 32 Gbps
Formfactor :
1U or 2U rack-mountable
Brand Name :
Brocade
MOQ :
1pcs
Price :
Negotiable
Redundancy :
Dual power supplies and fans
Delivery Time :
5-7 work days
Supportedprotocols :
Fibre Channel, FICON, FCIP
Description

Brocade Fiber Switch 7850 Extension Aes256 Encryption 650W Hot Swappable

Product Description

The Brocade 7850 Extension Switch is a 1U FCIP extension switch purpose‑built for long‑distance FC storage network connectivity across WANs. It features 24 equivalent FC ports (8 SFP+ + 8 SFP‑DD, auto‑sensing 8/16/32/64G) with 460ns latency, plus 16 x 1/10/25GbE ports and 2 x 100GbE ports (or 4 x 10GbE breakout). With AES‑256 hardware encryption at line rate (no performance loss), dual 650W hot‑swap redundant PSUs, 6 hot‑swap redundant fans, and up to 25 Gb/s per VE port, the 7850 is ideal for secure, high‑performance disaster recovery and remote replication.

Key Differentiators

  • 24 FC ports (8 SFP+ + 8 SFP‑DD) — 8/16/32/64G auto‑sensing

  • 16 x 1/10/25GbE SFP+ + 2 x 100GbE QSFP (or 4 x 10GbE breakout)

  • 460ns FC latency @ 64G — non‑blocking shared memory

  • AES‑256 hardware encryption — line rate, zero performance loss

  • WAN optimization: load balancing and failover across multiple WAN links

  • 25 Gb/s maximum rate per VE port (single circuit)

  • Minimum circuit bandwidth: 50 Mb/s

  • Dual 650W hot‑swap redundant AC PSUs

  • 6 hot‑swap redundant fans

  • Processor: Intel Atom dual‑core + Cavium CN7890 (1.2GHz)

  • Memory: 8GB control plane + 32GB data plane

  • All ports enabled by default, full bandwidth

  • Open Systems and Mainframe FICON versions available

Specifications

Category Specification
Model Brocade 7850 Extension Switch
Form Factor 1U rackmount
FC Physical Ports 8 SFP+ + 8 SFP‑DD = 24 equivalent FC ports
FC Speeds 8/16/32/64G, auto‑sensing
FC Latency 460 ns @ 64G
GbE Ports 16 x 1/10/25GbE SFP+
100GbE Ports 2 x 100GbE QSFP (or 4 x 10GbE breakout)
Management Port 1 x RJ‑45 1000Mb/s Ethernet
Encryption AES‑256 hardware, line rate
Max Rate per VE Port 25 Gb/s (single circuit)
Min Circuit Bandwidth 50 Mb/s
Processor Intel Atom dual‑core + Cavium CN7890 1.2GHz
Memory 8GB control + 32GB data plane
Power Supply Dual 650W hot‑swap redundant AC
Fans 6 hot‑swap redundant
Max Power Consumption 650W
Dimensions (HxWxD) 4.4 x 44.0 x 59.03 cm
Weight (unloaded / loaded) 12.0 kg / 12.9 kg
Operating Temp 0° to 40° C
Max Noise 89.9 dB
