4000kw 100T/H MVR Steam Compressor In Alkali Chemical Plants
4000kw 100T/H MVR Steam Compressor In Alkali Chemical Plants
4000kw 100T/H MVR Steam Compressor In Alkali Chemical Plants
4000kw 100T/H MVR Steam Compressor In Alkali Chemical Plants
4000kw 100T/H MVR Steam Compressor In Alkali Chemical Plants
4000kw 100T/H MVR Steam Compressor In Alkali Chemical Plants
Specifications
Supply Ability :
Single item，60-90 days
machinery test report :
Provided
core components :
PLC, Pressure Vessel, Engine, Gear, Motor, Pump, Bearing, Gearbox, Other
Certification :
Fully certified
power source :
DC Power
Model Number :
customization
gas type :
customize
New process :
Explosion-proof and anti-surge valve regulation
MOQ :
1 Pcs
Delivery Time :
60-90 days
Cooling Method :
customize
video outgoing-inspection :
Provided
Noise level :
Low Noise Air Compressor
Payment Terms :
L/C,T/T
voltage :
380 V
Application :
Food, steel, petrochemical, biopharmaceutical, fertilizer industry
OEM :
OEM Services Provided
Price :
Single item，250000 USD
configuration :
Stationary
Power :
customized for customers
Brand Name :
laishun
type :
Steam compressor
After-sales Service Provided :
Engineers
Place of Origin :
Chongqing, China
lubrication style :
Lubricated
Packaging Details :
Customized wooden box, customized iron box
mute :
Yes
Description
Fully Customized Steam Compressor for Power 4000kW 100T/H MVR System
This specialized steam compressor is engineered for 100T/H MVR systems operating in alkali chemical plant environments. Key specifications include an evaporation temperature of 100℃, temperature rise of 18℃, installed power of 4000kW, and single ton steam consumption of 38kW·h.
Centrifugal compression represents the optimal choice for MVR systems employed in processes such as evaporation crystallization, concentration, and temperature/pressure increase applications.
Model Features
  • Variable frequency/imported regulation
  • Remote monitoring service with automatic control
  • Intelligent anti-surge control for unmanned operation
  • Comprehensive research and system optimization matching
  • External sealing structure for easy maintenance
  • Oil-free compressed steam with stable pressure and low noise
  • High efficiency and energy savings with isentropic efficiency >82%
  • Modular and serialized design balancing speed, quality, and service
  • Customized services tailored to customer requirements
MVR Evaporator Performance Comparison
Parameter Single Effect Evaporator Multi-effect Evaporator MVR Evaporator
Energy Consumption High energy consumption, theoretically requires 1 ton of steam to evaporate 1 ton of water More energy-efficient, with decreasing consumption as efficiency increases Most energy-efficient technology, requires only 15-50kW·h electricity per ton of water evaporated
Floor Area Small Large Small
Impact on Product Quality Short dwell time but high temperature, minimal impact Long dwell time with high temperature, minimal impact Short residence time, evaporation via temperature difference, minimal impact
Energy Mode Requires steam heating, steam pipeline network and boiler Requires steam heating, steam pipeline network and boiler Electricity only, no steam network required, fully self-closing circulation system
Operating Cost High Higher Low
Stability Poor Poor Good
