16T/H Multi Stage Centrifugal Compressor MVR Compressor Explosion Proof
16T/H Multi Stage Centrifugal Compressor MVR Compressor Explosion Proof
16T/H Multi Stage Centrifugal Compressor MVR Compressor Explosion Proof
16T/H Multi Stage Centrifugal Compressor MVR Compressor Explosion Proof
16T/H Multi Stage Centrifugal Compressor MVR Compressor Explosion Proof
16T/H Multi Stage Centrifugal Compressor MVR Compressor Explosion Proof
Specifications
Supply Ability :
Single item，60-90 days
machinery test report :
Provided
Product name :
multistage compressor
Model Number :
customization
gas type :
customize
After-sales Service Provided :
Engineers
Price :
Single item，250000 USD
configuration :
Stationary
Power :
customized for customers
Certification :
CE, ISO9001, IS014001, HSAS18001, IATF16949 system certification CCS、DNV
MOQ :
1 Pcs
Delivery Time :
60-90 days
Cooling Method :
customize
video outgoing-inspection :
Provided
New process :
Explosion-proof and anti-surge valve regulation
Payment Terms :
L/C,T/T
voltage :
380 V
Application :
customize
OEM :
OEM Services Provided
power source :
DC Power
Brand Name :
LAISHUN
type :
Multi stage centrifugal compressor
Place of Origin :
Chongqing, China
lubrication style :
Lubricated
Packaging Details :
Customized wooden box, customized iron box
core components :
PLC, Pressure Vessel, Engine, Gear, Motor, Pump, Bearing, Gearbox, Other
Description
On-Site Steam Compressor for Special Environment 16T/H Two-Stage Pipeline Boosting System
Custom engineered steam compressor solution for new energy enterprises, featuring a 16T/H two-stage pipeline boosting system designed for specialized environmental conditions.
Technical Specifications
Inlet Conditions: 152℃ temperature, 0.3Mpa pressure
Exhaust Conditions: 182℃ temperature, 1.05Mpa pressure
Installed Power: 1250kW
Energy Efficiency: 62.5kW·h per ton of steam
Product Features
  • Gear speed integrated multi-stage compressor design
  • Imported guide vane pre-rotation with automatic control
  • Constant back pressure with 70%~100% adjustable air volume range
  • Specifically designed for process gas compression applications
  • Automatic anti-surge protection system
  • Compact structure for easy maintenance access
  • Oil-free compressed air delivery with stable pressure and low noise
  • Remote monitoring and automatic control capabilities
  • Fully customizable services tailored to customer requirements
MVR Evaporator Performance Comparison
Parameter Single Effect Evaporator Multi-Effect Evaporator MVR Evaporator
Energy Consumption High energy consumption (1 ton steam per 1 ton water) More energy-efficient with decreasing consumption per effect Most energy-efficient (15-50 kW·h per ton of water)
Floor Area Small Large Small
Product Quality Impact Short dwell time, high temperature, minimal impact Long dwell time, high temperature, minimal impact Short residence time, temperature difference evaporation, minimal impact
Energy Mode Steam heating requiring pipeline network and boiler Steam heating requiring pipeline network and boiler Electric only, no steam network required, fully closed circulation
Operating Cost High Higher Low
Stability Poor Poor Good
Key Advantage: MVR evaporators represent the most energy-efficient evaporator technology available, offering significant operational cost savings while maintaining high system stability and minimal product quality impact.
