Customized MVR Steam Compressor 28T/H Mechanical Vapor Recompression System
Customized MVR Steam Compressor 28T/H Mechanical Vapor Recompression System
Customized MVR Steam Compressor 28T/H Mechanical Vapor Recompression System
Customized MVR Steam Compressor 28T/H Mechanical Vapor Recompression System
Customized MVR Steam Compressor 28T/H Mechanical Vapor Recompression System
Customized MVR Steam Compressor 28T/H Mechanical Vapor Recompression System
Specifications
Supply Ability :
Single item，60-90 days
machinery test report :
Provided
core components :
PLC, Pressure Vessel, Engine, Gear, Motor, Pump, Bearing, Gearbox, Other
Model Number :
customization
gas type :
customize
OEM :
OEM Services Provided
Application :
customize
MOQ :
1 Pcs
Delivery Time :
60-90 days
Cooling Method :
customize
video outgoing-inspection :
Provided
Certification :
CE, ISO9001, IS014001, HSAS18001, IATF16949 system certification CCS、DNV
Payment Terms :
L/C,T/T
voltage :
380 V
Product name :
multistage compressor
Power :
customized for customers
Price :
Single item，300000 USD
configuration :
Stationary
air capacity :
customize
power source :
DC Power
Brand Name :
LAISHUN
type :
MVR steam compressor
New process :
Explosion-proof and anti-surge valve regulation
Place of Origin :
Chongqing, China
lubrication style :
Lubricated
Packaging Details :
Customized wooden box, customized iron box
mute :
Yes
Description
Fully Customized Steam Compressor for 28T/H MVR System
This specialized steam compressor is designed for new energy lithium-ion factory environments, featuring an inlet steam temperature of 75°C, pressure of 38.6Kpa, exhaust temperature of 93°C, pressure of 78.6Kpa, installed power of 1450kw, and single ton steam consumption of 43kw*h.
Centrifugal compression represents the optimal choice for MVR systems used in processes including evaporation crystallization, concentration, and temperature/pressure increase applications.
Model Features
  • Variable frequency/imported regulation
  • Remote monitoring service with automatic control
  • Intelligent anti-surge control for unmanned operation
  • Comprehensive research and system optimization matching
  • External sealing structure for easy maintenance
  • Oil-free compressed steam with stable pressure and low noise
  • High efficiency and energy savings with isentropic efficiency greater than 82%
  • Modular and serialized design emphasizing speed, quality, and service
  • Customized services tailored to customer requirements
MVR Evaporator Performance Comparison
Compared to other evaporator types, MVR evaporators offer the lowest energy consumption, compact footprint, minimal product quality impact, simple control systems, and high operational stability.
Parameter Single Effect Evaporator Multi-effect Evaporator MVR Evaporator
Energy Consumption High energy consumption, theoretically requiring 1 ton of steam to evaporate 1 ton of water More energy-efficient, with consumption decreasing as efficiency increases Most energy-efficient technology, requiring only 15-50KW/h electricity per ton of water evaporated
Floor Area Small Large Small
Impact on Product Quality Short dwell time but high temperature, minimal impact Long dwell time, high temperature, minimal impact Short residence time, evaporation via temperature difference, minimal impact
Energy Mode Steam heating requiring steam pipeline network and boiler Steam heating requiring steam pipeline network and boiler Electricity only, no steam network required, fully self-closing circulation system
Operating Cost High Higher Low
Stability Poor Poor Good
