Plain Twilled 3um-300um Stainless Steel Woven Mesh Hollander Weave Mesh
Plain Twilled 3um-300um Stainless Steel Woven Mesh Hollander Weave Mesh
Plain Twilled 3um-300um Stainless Steel Woven Mesh Hollander Weave Mesh
Plain Twilled 3um-300um Stainless Steel Woven Mesh Hollander Weave Mesh
Specifications
Brand Name :
JIUFU
Model Number :
JF-10022
Certification :
ISO
Place of Origin :
ANPING, CHINA
MOQ :
10 Square Meter
Price :
negotiation
Payment Terms :
T/T, Western Union
Supply Ability :
10000 Square Meter per Day
Delivery Time :
7-20 days
Packaging Details :
Plastic Film + Water-proof Paper + Woven Bag + Wooden Box or Pallet
Product Name :
Hollander Weave Mesh
Weave Type :
Plain Twilled
Material :
304 316 316L
Wire Diameter :
0.019mm-0.63mm
Mesh Count :
8-3000mesh
Feature :
hollander waave
Application :
filters
Aperture :
3um-300um
Technique :
Woven mesh
Edge Finish :
Flash Edge
Description

Plain Twilled 3um-300um Stainless Steel Woven Mesh Hollander Weave Mesh

Hollander Weave Stainless Steel Wire Mesh, same as Stainless Steel Dutch Wire Mesh

Hollander weave, a plain weave or twilled weave with the warp wires of larger diameter than the weft wire. The weave is made up of a limited number of warp wires interwoven with the maximum number of weft wires which can be knocked up.

Feature: this cloth is strong and firm, micron-scale small mesh size.

Application: most frequently used for high pressure filtration.

Plain Twilled 3um-300um Stainless Steel Woven Mesh Hollander Weave Mesh

Hollander Weave Mesh Parameter

Product Name
Hollander Weave Mesh, Dutch Wire Mesh
Material
Stainless steel wire, Nickel wire, Black iron wire, Copper wire, etc
Wire Diameter
0.018-0.6mm
Weave Type
Plain Dutch Weave; Twilled Dutch Weave
Width
1m-1.6m
Feature
Stable and Fine Filtration Performance
Application
Used for precision pressure filter, fuel filter, vacuum filter, also suitable for aerospace, petroleum, chemical, chemical fiber, rubber, tire manufacturing, metallurgy, medicine, food and other industries.
Common Specifications
12 x 64 mesh * 0.58mm x 0.40mm * 280um
24 x 110 mesh * 0.355mm x 0.25mm * 120um
30 x 150 mesh * 0.25mm x 0.18mm * 80um
45 x 250 mesh * 0.16mm x 0.112mm * 56um
70 x 350 mesh * 0.11mm x 0.08mm * 35um
127 x 1100 mesh * 0.07mm x 0.05mm * 17um
165 x 1400 mesh * 0.071mm x 0.04mm * 16um
200 x 1400 mesh * 0.071mm x 0.04mm * 12um
254 x 2000 mesh * 0.04mm x 0.028mm * 8um
325 x 2300 mesh * 0.035mm x 0.025mm * 5um
400 x 3100 mesh * 0.035mm x 0.019mm * 3um

Hollander Weave Mesh Packing and Transporation

Plain Twilled 3um-300um Stainless Steel Woven Mesh Hollander Weave Mesh

Plain Twilled 3um-300um Stainless Steel Woven Mesh Hollander Weave Mesh
