Food Industry Stainless Steel Fermentation Tanks Double Jacketed Insulated
Food Industry Stainless Steel Fermentation Tanks Double Jacketed Insulated
Food Industry Stainless Steel Fermentation Tanks Double Jacketed Insulated
Food Industry Stainless Steel Fermentation Tanks Double Jacketed Insulated
Food Industry Stainless Steel Fermentation Tanks Double Jacketed Insulated
Food Industry Stainless Steel Fermentation Tanks Double Jacketed Insulated
Specifications
Model Number :
KQ Series
Certification :
SGS ,ISO
MOQ :
1Sets
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
25 days after get your advance payment
Packaging Details :
Standard Export Wooden Cases / Pallet
Name :
industrial fermentation tank
Capacity :
100L to 1000L
Heating :
Steam Heating / Electric heating /Gas Heating
Electric Control Box :
Yes / No
Thickness :
According to your requirement .
Working Pressure :
Based on your order
Description

Food Industry Stainless Steel Double Jacketed Insulated Mixing Fermentation Tanks

1. Introduction of Stainless Steel Fermentation Tanks :

0~200rpm Adjustable Speed Mixing Tank for Milk Juice Production
Customer Sase

300L capacity mixing tank, used to mixing whole milk powder into water for nature set yogurt processing.
0~200rpm mixing speed
380V 50Hz 3phase
No heating, no insulation needed

what we are going to offer - Tank description

Based on the above request, this tank will be
a single wall mixing tank,
with conical bottom,
with hinged cover on tank top.
Top mount mixer with 0~200rpm adjustable speed.
In order to avoid any dust goes into this tank, there should be a anti-dust cap (made of silicon, food grade) on this tank. (machnical sealing is optional)

3. Technical Parameter :

Description Designed according to 3A standard, widely used for transfer viscous media in the food-processing, beverage, chemical, cosemtics and pharmaceutical industries
Construction Horizontal and vertical; Open lid, flat, disc, conical, shell cover;
Material SS304/SS316L/1.4301/1.4404
Seal Ring Fluorine Rubber, EPDM, PTFE, Silicone(Standard, FDA approval)
Mechnical Seal SIC, Hard alloy, graphite
Volume 50-30000L
Pressure 0-2 bar
Working temperature 300 C / 572 F
Jacket Coil, dimple jacket, hollow jacket
Cooling Water, coolant, compressor
Heating Electric(water, oil), steam
Agitator Stirrer, high shear homogenizer, scrap mixer
Agitator Speed Constand speed and variable speed; Range: 0-4000rpm
Motor power 0.37kw-100kw
Voltage 110V/220V/240V/380V/415V/460V (50/60Hz)
Motor Siemens, ABB, Domestic
Automitac PLC/HMI control, display, store, transfer
Surface treatment Inner and externel polished and brushed, good weldings and joints;
Accessories Customizable support
Availably connection Clamp, Thread, Butt weld, Flange
Availably standard DIN, SMS, 3A, RJT, ISO/IDF
Application scope Dairy, food, beverage, chemical, pharmacy, cosmetic, etc
Packaging Details Plywood case or customerized. Or as per the request of customers
Delivery details Usually within 25 days after receiving T/T down payment, special customized need negotiation.

Food Industry Stainless Steel Fermentation Tanks Double Jacketed Insulated
