Durable Stainless Steel Fermentation Tanks Jacketed Mixing Vessel GMP Approved
Durable Stainless Steel Fermentation Tanks Jacketed Mixing Vessel GMP Approved
Durable Stainless Steel Fermentation Tanks Jacketed Mixing Vessel GMP Approved
Durable Stainless Steel Fermentation Tanks Jacketed Mixing Vessel GMP Approved
Durable Stainless Steel Fermentation Tanks Jacketed Mixing Vessel GMP Approved
Durable Stainless Steel Fermentation Tanks Jacketed Mixing Vessel GMP Approved
Specifications
Model Number :
KQ 1000L KQ 2000L KQ3000L
Certification :
CE ,SGS ,GMP
MOQ :
1Set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
200 Sets Per Month
Delivery Time :
20 to 25 days after get your advance payment
Packaging Details :
Standard Export Wooden Box
Name :
jacketed stainless steel mixing tanks
Material :
Stainless Steel 304 / 316 /316L
Capacity :
100L to 10000L
Heating :
Steam heating or electric heating
Speed of mixer :
18RPM , 36RPM ,48RPM ,72RPM ,2900RPM
Surface Treatment :
Inside mirror and outside polished
Motor Brand :
Siemens / ABB / SEW
Description

304 316 Stainless Steel Heating Jacketed Insulationed Fermentation Fermenter Tank

1. Introduction of Stainless Steel Fermentation Tank

SS304/SS316 Agitator Mixing Pot Drum for Milk, Juice is mainly used for stirring and storing milk, sugar, beverage, food, other elements and various drugs after mixing. Mixing tank, also known as mixing tank, mixing cylinder, hot and cold cylinder, bucket, storage tank, temporary tank, energy saving, corrosion resistance, strong production capacity, easy cleaning, simple structure, etc., mainly for dairy and Sugar and other elements and all kinds of drugs and then mix even after mixing, dairy, beverages, pharmaceuticals indispensable equipmen


2. Classification:

a. By heating method: electric heating, steam heating, cooling
b. Single layer, PU insulation layer, jacket layer (Miller jacket and coil jacket)
c. Stirring structure: top center stirring, top eccentric stirring, side stirring
d. Open, sealed
e. Volume: 100L-20000L

3. Tank configuration (customized):

1. Quick opening manhole
2. Various types of CIP
3. Anti butterfly and dirt air vent
4. Tubular or triangular legs
5. Inlet and outlet valve
6. Thermometer
7. Ladder
8. Jacket (Miller jacket or hollow jacket)
9. PU insulation layer
10. Mixer
11. Level gauge and level controller
12. Anti-vortex board
13. Sanitary sample valve

4. Technical Parameter :

olume 300L 400L 500L 600L 800L 1000L 1500L 2000L 3000L
Body diameter(mm) Φ800 Φ800 Φ900 Φ1000 Φ1000 Φ1000 Φ1200 Φ1300 Φ1600
Body height(mm) 600 800 800 800 1000 1220 1220 1500 1500
Motor power(KW) 0.55 0.55 0.75 0.75 0.75 0.75 1.5 2.2 3
Stirring speed (rpm) 36r/min
Working pressure Based on your order
Working Temperature <100
Accessories Sanitary manholecleaning ballsafety valvepressure gauge
